Essential Nut Weight Chart in KG and MM Specifications
Complete Hex Nut Weight Chart
Standard Metric Hex Nuts (Carbon Steel)
Size (MM) | Thread Pitch | Weight (g/piece) | Weight (KG/1000 pcs) | Width Across Flats | Height | Diagonal | Material Density |
M3 x 0.5 | 0.5 | 0.18 | 0.18 | 5.5mm | 2.4mm | 6.35mm | 7.85 g/cm³ |
M4 x 0.7 | 0.7 | 0.45 | 0.45 | 7mm | 3.2mm | 8.08mm | 7.85 g/cm³ |
M5 x 0.8 | 0.8 | 0.89 | 0.89 | 8mm | 4mm | 9.24mm | 7.85 g/cm³ |
M6 x 1.0 | 1.0 | 1.52 | 1.52 | 10mm | 5mm | 11.55mm | 7.85 g/cm³ |
M8 x 1.25 | 1.25 | 3.45 | 3.45 | 13mm | 6.5mm | 15.01mm | 7.85 g/cm³ |
M10 x 1.5 | 1.5 | 6.78 | 6.78 | 17mm | 8mm | 19.63mm | 7.85 g/cm³ |
M12 x 1.75 | 1.75 | 11.89 | 11.89 | 19mm | 10mm | 21.93mm | 7.85 g/cm³ |
M14 x 2.0 | 2.0 | 18.34 | 18.34 | 22mm | 11mm | 25.40mm | 7.85 g/cm³ |
M16 x 2.0 | 2.0 | 26.77 | 26.77 | 24mm | 13mm | 27.71mm | 7.85 g/cm³ |
M18 x 2.5 | 2.5 | 37.45 | 37.45 | 27mm | 15mm | 31.18mm | 7.85 g/cm³ |
M20 x 2.5 | 2.5 | 49.89 | 49.89 | 30mm | 16mm | 34.64mm | 7.85 g/cm³ |
M22 x 2.5 | 2.5 | 65.23 | 65.23 | 32mm | 18mm | 36.95mm | 7.85 g/cm³ |
M24 x 3.0 | 3.0 | 82.67 | 82.67 | 36mm | 19mm | 41.57mm | 7.85 g/cm³ |
M27 x 3.0 | 3.0 | 112.45 | 112.45 | 41mm | 22mm | 47.34mm | 7.85 g/cm³ |
M30 x 3.5 | 3.5 | 145.78 | 145.78 | 46mm | 24mm | 53.11mm | 7.85 g/cm³ |
Lock Nut Weight Specifications (All Materials)
Size (MM) | Carbon Steel (g) | Stainless A2 (g) | Stainless A4 (g) | Brass (g) | Nylon Insert Weight | Prevailing Torque |
M3 | 0.23 | 0.18 | 0.18 | 0.19 | +0.02g | 0.5-1.2 Nm |
M4 | 0.56 | 0.45 | 0.45 | 0.48 | +0.03g | 0.8-1.8 Nm |
M5 | 1.12 | 0.89 | 0.89 | 0.94 | +0.04g | 1.2-2.5 Nm |
M6 | 1.89 | 1.52 | 1.52 | 1.59 | +0.05g | 1.8-3.5 Nm |
M8 | 4.23 | 3.45 | 3.45 | 3.67 | +0.08g | 3.2-6.8 Nm |
M10 | 8.34 | 6.78 | 6.78 | 7.12 | +0.12g | 5.5-12 Nm |
M12 | 14.56 | 11.89 | 11.89 | 12.45 | +0.18g | 8.5-18 Nm |
M14 | 22.45 | 18.34 | 18.34 | 19.23 | +0.25g | 12-25 Nm |
M16 | 32.78 | 26.77 | 26.77 | 28.12 | +0.35g | 18-35 Nm |
M20 | 61.23 | 49.89 | 49.89 | 52.45 | +0.55g | 28-58 Nm |
Wing Nut and Special Nut Weights
Type | Size Range | Weight Formula | Material Options | Typical Weight (M10) |
Wing Nuts | M3-M20 | Base weight × 2.3 | Steel, Stainless, Brass | 15.6g |
Cap Nuts | M4-M24 | Base weight × 1.8 | Steel, Stainless | 12.2g |
Castle Nuts | M6-M30 | Base weight × 1.4 | Steel, Stainless | 9.5g |
Coupling Nuts | M5-M20 | Base weight × 2.8 | Steel, Stainless | 19.0g |
Thumb Nuts | M6-M16 | Base weight × 3.2 | Steel, Plastic, Stainless | 21.7g |
