Wire mesh is one of the most versatile materials used across industries ranging from construction and mining to agriculture and filtration. Whether you're reinforcing concrete, screening particles, or designing architectural panels, wire mesh weight chart in kg provides the strength, flexibility, and durability you need. It is available in a variety of materials, weaves, and gauges.
This guide explores common wire mesh specifications and includes weight charts to help engineers, procurement professionals, and manufacturers choose the right product for their applications. All mesh types mentioned below are available through Pipex.ai, a leading B2B platform for industrial supplies.
Weight Chart 1: Mild Steel Welded Wire Mesh (Standard Panels)
Mesh Size (mm) | Wire Diameter (mm) | Weight per m² (kg) | Sheet Size (m) |
50 x 50 | 2.5 | 2.5 | 2.4 x 1.2 |
25 x 25 | 3.0 | 4.8 | 2.4 x 1.2 |
75 x 25 | 4.0 | 6.2 | 2.4 x 1.2 |
100 x 100 | 5.0 | 8.1 | 2.4 x 1.2 |
Explanation:
Mild steel welded mesh is widely used in construction for reinforcing slabs, walls, and pavements. The mesh size refers to the spacing between wires, while the wire diameter affects strength and weight. For heavy-duty reinforcement, larger diameters and tighter mesh spacing (like 25 x 25 mm) are ideal. These panels are easy to install and cut, making them suitable for quick on-site fabrication.
Weight Chart 2: Stainless Steel Woven Wire Mesh
Mesh Count (per inch) | Wire Diameter (mm) | Weight per m² (kg) | Common Usage |
10 x 10 | 0.9 | 2.3 | Ventilation, Safety |
20 x 20 | 0.55 | 1.5 | Filtration, Sieving |
40 x 40 | 0.28 | 0.9 | Lab Screens, Insect Barriers |
80 x 80 | 0.16 | 0.45 | Fine Filtration |
Explanation:
Woven wire mesh is made by interlacing horizontal and vertical wires. Stainless steel variants are corrosion-resistant, making them perfect for chemical, marine, or food-grade environments. Mesh count indicates the number of openings per linear inch—higher counts are used for finer filtration. The lower the wire diameter, the lighter and more flexible the mesh becomes.
Weight Chart 3: Galvanized Wire Mesh Rolls
Opening Size (mm) | Wire Gauge (SWG) | Roll Width (m) | Roll Weight (kg per 10m) |
12 x 12 | 18 | 1.2 | 6.8 |
25 x 25 | 16 | 1.2 | 8.2 |
50 x 50 | 14 | 1.2 | 10.6 |
75 x 25 | 12 | 1.2 | 13.4 |
Explanation:
Common Wire Mesh Applications Across Industries
- Construction: Used for slab reinforcement, plastering support, and retaining walls.
- Agriculture: Ideal for fencing, cages, and enclosures for livestock or poultry.
- Mining & Quarrying: Heavy-duty mesh screens are used to sort and filter aggregate.
- Filtration: Woven wire mesh with high mesh count is critical in fluid and air filtration.
- Architecture: Designer mesh panels are used in facades, sunshades, and ceilings.
Key Selection Factors
When choosing wire mesh, consider the following:
- Material: Stainless steel for corrosion resistance; galvanized for outdoor use; mild steel for economy.
- Opening Size and Mesh Count: Defines the size of the particle it can block or allow.
- Wire Diameter or Gauge: Affects strength, flexibility, and weight.
- Sheet or Roll Form: Choose based on installation style and quantity needed.
Wire mesh is a crucial material across multiple industries due to its strength, versatility, and adaptability. By understanding the different types—welded, woven, and galvanized—you can select the most suitable mesh for your application. Use the wire mesh weight chart in PDF above to compare options and ensure your selection matches project specifications in terms of durability and load-bearing requirements.
If you're working on a large-scale project or sourcing mesh regularly, proper planning and selection based on specs like mesh size, gauge, and material type can make a big difference in cost and performance.
