Buttweld Elbow Factory Formed Pipe Fitting Designed To Change Flow Direction In Piping Lines Manufacturer In India
| Specifications | Astm, Asme, Din, Nf, Jis, En, Ios |
|---|---|
| Size Range | 1/2"nb To 48"nb, 1/2"nb, 48"nb |
| Dimension | Asme/ansi B16.9, Asme B16.28, Mss Sp 43 |
Buttweld Elbow Supplied in Standard Angles and Radius Options for Process and Utility Piping Systems Supplier in India
Timex Metals is the well-known Buttweld Elbow Manufacturer which has provided precision engineered pipe fittings that assure smooth flow of fluids and leak free performance. These elbows are made of high-quality stainless steel, carbon steel, and alloy steel to offer high-quality strength, corrosion, and resistance to operating in harsh industrial conditions. They are offered in different angles like 45, 90, and 180 degrees which makes them suitable in pipelines, petrochemical plants, power stations and even in water treatment systems. Both buttweld elbows are highly dimensioned and have a good surface finish to fit international quality standards.
Buttweld elbows enable the alteration of the flow direction within the oil, gas, chemical, and power plants piping systems. The proper choice of the material and the grade guarantees pressure integrity, ability and resistant to corrosion and long service. This table will help with proper sourcing by use of reliable B2B market place in Integrally Finned Tubes and other industrial products.
Material and Grades Table – Buttweld Elbow
Material / Grade | Standard Sizes (inch) | Weight per Meter (kg/m) | Notes / Applications |
|---|---|---|---|
| Carbon Steel ASTM A234 WPB | 1/2" – 48" | 1.0 – 45.0 | High strength, widely used in oil, gas, and power piping |
| Stainless Steel SS 304/304L | 1/2" – 48" | 0.9 – 42.0 | Corrosion-resistant, suitable for general industrial use |
| Stainless Steel SS 316/316L | 1/2" – 48" | 1.0 – 44.0 | Excellent resistance to chemicals and marine environments |
| Alloy Steel ASTM A234 WP11 | 1/2" – 36" | 1.2 – 46.0 | High temperature and pressure resistance |
| Duplex Stainless Steel 2205 | 1/2" – 24" | 1.1 – 40.0 | High strength and superior corrosion resistance |
- Direction change in Pipeline: Buttweld elbows are employed to redirect the flow direction in piping systems without having to change the internal diameter. Their continuous curving reduces flow velocity and turbulence and thus are necessitated in systems that have pressure-bearing fluid, gases, or steam.
- Angle Set-up & System Interchangeability: Buttweld elbows are available in 45 °, 90 degree and 180 degree configurations, but are typically chosen depending on the space, layout design and flow needs. Long radius elbows are used when the systems are designed to have high flow or erosion-prone piping whereas short radius is used in cases where the piping is to occupy compact layout.
- Production Process and Welding Finality: These elbows are produced through procedures of hot forming, extrusion or welding so that the wall thickness is uniform and the end is properly prepared. Reliable welds can only be made when the bevel angles and roundness are accurate and this is what is needed to maintain strong and defect free welds in the process of installation and the reliability of the joint in the long term.
- Degree of Material Grades and Service Reliability: Buttweld elbows are offered in Carbon Steel, Stainless steel, Alloy steel and nickel alloy as per the ASME B16.9 standards. The correct choice of material makes them resistant to pressure, change in temperature, and corrosion, thus suitable in refineries, power plants, chemical processing, or piping networks of industries.
Client Project Report of Buttweld Elbow
Product Supplied | Quantity | Cities (India) |
|---|---|---|
| Buttweld Elbows for High-Pressure Process Pipelines | 169 Pieces | Dahej |
| Buttweld Elbows for Refinery Transfer Lines | 207 Pieces | Vadinar |
| Buttweld Elbows for Power Plant Steam Piping | 182 Pieces | Koradi |
| Buttweld Elbows for Chemical Plant Utility Systems | 194 Pieces | Vapi |
Buttweld elbows are incorporated to redirect the flow in piping systems without interruption in the bore continuity and minimum pressure loss in the interior. Selection of grade of material and schedule have a direct influence on pressure processing and weld integrity in the long-term. Space constraints and flow behavior are the basis of the choice of elbow radius and bend angle. Butt Welded Cross fittings are usually scrutinized with the elbows to handle the distribution of the flow in more than one direction without jeopardizing the structural integrity of complex piping layouts.
Type of Sub-products
90 Degree Buttweld Elbow 90 Degree Buttweld Elbow
The most common elbow used to change flow direction by 90°, suitable for high pressure steam, chemical, and gas transmission systems with smooth flow transitions.
45 Degree Buttweld Elbow 45 Degree Buttweld Elbow
Used where a gradual change in flow direction is required. Ideal for petrochemical and water pipelines to reduce stress and maintain hydraulic efficiency.
