Hastelloy C22 Sheet Manufacturer In India Delivering Export Quality Sheets Conforming To Astm, Asme & En Standards
| Size range | 1000 Mm X 2000mm, 1220mm X 2440mm, 4' X 8', 1250mm X 2500mm, 1500mm X 3000mm To 6000mm, 2000mm X 4000mm To 6000mm |
|---|---|
| Range | 5mm, 150mm |
| Thickness | 4.0mm, 100mm |
| Specialize | Shim Sheet, Perforated Sheet |
Hastelloy C22 Sheet Manufacturer in India Supplying ASTM B575 / ASME SB575 Standard Sheets for Chemical Processing Plants
United Stainless LLP is a major Hastelloy C22 Sheet Manufacturer In India, which produces high quality nickel-chromium-molybdenum alloy sheets used in exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking. Hastelloy C22 sheets find extensive applications in chemical processing, pharmaceuticals, flue gases desulfurization systems and marine applications in which there is likelihood of exposure to aggressive chemicals that may require exceptionally high levels of material reliability.
These sheets are available in a big variety of thicknesses and surface finishes and are offered by a reliable B2B portal to meet the needs of sensitive applications. Its product portfolio also extends to Hastelloy Sheets, which are used in the multi-industry corrosion resistance as well as Hastelloy C276 Sheets, which is applied in a situation that needs any proven performance in mixed acid environment.
Hastelloy C22 Sheet offers high levels of weldability, ease of fabrication and long life span under extreme service conditions. These sheets are reliable Hastelloy C22 Sheet Supplier In India and are mostly applicable in reactors, heat exchangers, scrubbers, and pressure vessels where the requirements are safety, uniformity, and corrosion resistance. We supply Nickel Alloy Sheets offering exceptional corrosion resistance and high-temperature strength for critical applications.
Material & Grades of Hastelloy C22 Sheet
Hastelloy C22 Sheet is made under strict quality standards of maintaining uniform chemical composition and mechanical strength and this makes it fit to challenging industrial conditions.
| Material | Grade / Standard | UNS No. | Thickness (mm) | Width (mm) | Typical Applications |
|---|---|---|---|---|---|
| Hastelloy Alloy | C22 | N06022 | 0.5 – 40.0 | 1000 – 2000 | Chemical reactors |
| Hastelloy Alloy | C276 | N10276 | 0.5 – 35.0 | 1000 – 2000 | Pollution control |
| Hastelloy Alloy | C2000 | N06200 | 0.8 – 30.0 | 1000 – 2000 | Acid processing |
| Hastelloy Alloy | X | N06002 | 1.0 – 25.0 | 1000 – 1500 | Petrochemical units |
Key Features & Advantages
- Exceptional resistance to pitting and crevice corrosion
- High stability in oxidizing and reducing environments
- Excellent weldability and formability
- Suitable for severe chemical processing conditions
- Long service life with minimal maintenance
- Available in standard and custom sizes
Hastelloy C22 Sheet Chemical Composition
Hastelloy C22 Sheets are corrosion resistant due to the presence of carbon, silicon, sulfur, and other elements.
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
|---|---|---|---|---|---|---|---|---|---|---|
| C22 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
Hastelloy C22 Sheet Mechanical Properties
Mechanical Properties of Hastelloy C22 Sheets are listed below to assist you understand the product's durability.
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| C22 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
Hastelloy C22 Sheet Equivalent Grade
Our dedication to quality guarantees that every Hastelloy C22 meet the highest standards, establishing us as a reliable Hastelloy C22 Sheet Manufacturer in India.
| Standard | WERKSTOFF NR. | UNS | JIS | EN |
|---|---|---|---|---|
| Hastelloy C22 | 2.4602 | N06022 | NW 6022 | NiCr21Mo14W |
Hastelloy C22 Sheet Size Chart
Hastelloy C22 Sheets may be customized in any thickness to meet the needs of the client; the table below shows the standard thickness of Hastelloy C22 Sheet.
| Width (mm) | Length (mm) |
|---|---|
| 914 & 1219 | 1828 & 2438 |
| 914, 1219 & 1500 | 1828, 2438, 3000, 3048 & 3658 |
| 1219 | 2438 |
| 1219 & 1500 | 2438, 3000 & 3658 |
| 1500 & 2000 | 3000 & 6000 |
| 914 & 1219 | 1828 & 2438 |
| 1250 | 2500 |
| 1250 & 1500 | 2500, 3000 & 6000 |
