Customized Crimped Wire Mesh Manufacturer & Supplier | Stainless Steel Ss 304 & Ss 316 Grade | H M B Engineering

Customized Crimped Wire Mesh Manufacturer & Supplier | Stainless Steel Ss 304 & Ss 316 Grade | H M B Engineering
Specification Details
StandardAstm A580, A313, A555, A493 / Asme Sa580, Sa313, Sa555, Sa493, Ams 5514
Length0.125", 72
Diameter10 Microns 1.0 Mm, 0.0004" To 0.040"
TechniqueCold Rolled, Hot Rolled

HMB Crimped Wire Mesh – Rugged, Rigid, and Reliable

HMB Engineering proudly offers Crimped Wire Mesh, crafted with precision for heavy-duty industrial applications. Each wire is pre-crimped prior to weaving, ensuring a tight, interlocking mesh that delivers superior rigidity, strength, and dimensional accuracy—far beyond regular woven mesh Whether you specify double crimp, lock crimp, or flat-top crimp, our mesh stays stable even under high stress Ideal for use in vibrating screens, heavy screening, filtration, separation, construction, mining, and architectural panels, HMB’s Crimped Wire Mesh combines function with longevity Manufactured using high-grade materials—such as stainless steel, galvanized steel, or spring steel—our mesh withstands harsh industrial environments with minimal maintenance.


Material & Grades Table – HMB Crimped Wire Mesh

MaterialGrade / StandardWire Diameter / Opening (mm)Extra SpecificationWeight (kg/m²)
High Carbon SteelASTM A5102.0 – 12.0 / 5 – 100Heavy Duty / Abrasion Resistant8 – 55
Spring SteelEN 10270-12.0 – 12.0 / 5 – 100High Tensile / Pre-Crimped8 – 55
Stainless SteelSS 304 / ASTM A5801.0 – 8.0 / 3 – 75Corrosion Resistant4 – 40
Stainless SteelSS 316 / ASTM A5801.0 – 8.0 / 3 – 75Marine / Chemical Service4 – 40
Manganese SteelHadfield Steel3.0 – 12.0 / 5 – 100High Impact / Wear Resistant10 – 60
Duplex SteelUNS S322051.5 – 8.0 / 5 – 75High Corrosion Resistance5 – 42
Alloy SteelHigh Tensile Alloy Steel2.0 – 10.0 / 5 – 100Mining / Quarry Grade8 – 50
Nickel AlloyInconel 6251.0 – 6.0 / 3 – 50High Temperature Service4 – 30

Key Features & Advantages

  • High rigidity and dimensional stability
  • Excellent abrasion and wear resistance
  • Consistent openings for accurate material separation
  • Suitable for heavy-duty vibrating screen applications
  • Multiple crimping patterns available
  • Good mechanical strength under continuous vibration
  • Customized wire diameters, openings, and panel sizes available

Chemical Composition

Representative Grade: High Carbon Steel SAE 1060

ElementPercentage (%)
Carbon (C)0.55–0.65
Manganese (Mn)0.60–0.90
Silicon (Si)0.15–0.35
Phosphorus (P)0.040 max.
Sulfur (S)0.050 max.
Iron (Fe)Balance

Mechanical Properties

PropertyValue
Tensile StrengthApprox. 620–850 MPa
Yield StrengthApprox. 350–600 MPa
ElongationApprox. 10–20%
HardnessApprox. 180–250 HB

Equivalent Grade

StandardGrade
ASTMSAE 1060
UNSG10600
ENC60E
DINC60



Type of Sub-products

Frequently Asked Questions

What is crimped wire mesh?

What are the types of crimp styles available?

What materials can be used?

Where is crimped mesh typically used?

Why choose HMB Crimped Wire Mesh?
