Minimum Order : 300 Items
Customization as per requiments
| Flanges Types | Slip On, Companion, Weld Neck, Lap Joint, Long Weld Neck, Threaded, Blind |
| Class | 150 Lbs, 100, 160, 300 Lbs, 600 Lbs, 900 Lbs, Asa 300, Pn 6, 10, 16, 1500 Lbs, 25, 40, 64, 2500 Lbs Asa 150 |
| Size | 48″ (1200nb) Dn10~dn5000, 1/2″ (15 Nb) |
| Type | Raised Face (rf), Lap Joint Face (ljf), Small Male Female (smf), Groove, Large Tongue & Groove, Large Male Female (lmf), Flat Face (ff), Ring Type Joint (rtj), Small Tongue |
Standard Weld Neck Flanges are designed with a long tapered hub that gradually transitions into the pipe, providing superior strength and resistance to dishing. This design minimizes stress concentration at the base of the flange, making it ideal for high-pressure and high-temperature applications. Commonly used in petrochemical, power generation, and shipbuilding industries, they ensure a smooth flow with minimal turbulence.
Raised Face Weld Neck Flanges feature a slightly elevated surface around the bore where the gasket is seated, enhancing the sealing efficiency under pressure. The raised face allows for greater gasket compression, improving the joint integrity in demanding pipeline systems. These flanges are widely preferred in process plants, chemical refineries, and fluid transport networks.
What are the advantages of Weld Neck Flanges?
Weld neck flanges provide excellent structural strength, making them suitable for high-pressure and high-temperature applications. Their tapered hub design reduces stress concentration at the weld joint, minimizing the risk of failure under extreme conditions. These flanges offer superior leak-proof connections, ensuring reliability in critical piping systems. Additionally, their smooth bore design allows for optimal fluid flow, reducing turbulence and preventing erosion at the joint.
Where are Weld Neck Flanges used?
Weld neck flanges are widely used in industries that require high-strength, corrosion-resistant, and durable piping systems. They are commonly found in oil refineries, petrochemical plants, power plants, shipbuilding, and marine applications. These flanges are essential in pipelines carrying hazardous fluids, steam, or gases under high pressure, ensuring a secure and leak-free connection that enhances operational safety.
How do Weld Neck Flanges differ from other flange types?
Unlike slip-on or socket weld flanges, weld neck flanges feature a long hub that provides additional reinforcement and structural integrity. This design reduces mechanical stress at the weld joint, making them more reliable for extreme conditions. They are specifically used for high-pressure and high-temperature applications, where maintaining a leak-proof and strong connection is crucial. Their superior performance and durability make them the preferred choice for critical industries.
