Forged Pipe Weight Chart in kg, mm, pdf specifications enable precise calculations for industrial piping systems requiring optimal design performance and structural integrity. These premium-grade piping solutions utilize hot forging processes to enhance material strength, eliminate internal defects, and create seamless configurations with exceptional pressure resistance for high-stress applications in petrochemical, power generation, and offshore drilling environments including high-pressure transmission lines, steam generation systems, boiler interconnections, refinery processing, corrosive media handling, and reactor system piping across diverse industrial sectors.
Essential Forged Pipe Weight Chart Specifications in kg and mm
Detailed Forged Pipe Weight Chart
Carbon Steel Forged Pipes (ASTM A105)
Nominal Size (inches) | Outside Diameter (mm) | Wall Thickness (mm) | Weight per Meter (kg) | Internal Diameter (mm) | Cross-sectional Area (cm²) |
1/2 | 21.3 | 2.8 | 1.27 | 15.7 | 1.62 |
3/4 | 26.7 | 2.9 | 1.69 | 20.9 | 2.15 |
1 | 33.4 | 3.4 | 2.50 | 26.6 | 3.18 |
1-1/4 | 42.2 | 3.6 | 3.39 | 35.0 | 4.31 |
1-1/2 | 48.3 | 3.7 | 4.05 | 40.9 | 5.16 |
2 | 60.3 | 3.9 | 5.44 | 52.5 | 6.93 |
2-1/2 | 73.0 | 5.2 | 8.63 | 62.6 | 10.99 |
3 | 88.9 | 5.5 | 11.29 | 77.9 | 14.37 |
4 | 114.3 | 6.0 | 16.07 | 102.3 | 20.46 |
5 | 141.3 | 6.6 | 22.32 | 128.1 | 28.43 |
6 | 168.3 | 7.1 | 28.89 | 154.1 | 36.79 |
8 | 219.1 | 8.2 | 44.16 | 202.7 | 56.21 |
10 | 273.0 | 9.3 | 63.38 | 254.4 | 80.65 |
12 | 323.9 | 9.5 | 78.60 | 304.9 | 100.1 |
14 | 355.6 | 9.5 | 87.39 | 336.6 | 111.3 |
16 | 406.4 | 9.5 | 100.33 | 387.4 | 127.7 |
18 | 457.2 | 9.5 | 113.28 | 438.2 | 144.2 |
20 | 508.0 | 9.5 | 126.22 | 489.0 | 160.7 |
24 | 610.0 | 9.5 | 152.11 | 591.0 | 193.6 |
Stainless Steel Forged Pipes (ASTM A182 F316L)
Nominal Size (inches) | Outside Diameter (mm) | Wall Thickness (mm) | Weight per Meter (kg) | Internal Diameter (mm) | Cross-sectional Area (cm²) |
1/2 | 21.3 | 2.8 | 1.42 | 15.7 | 1.81 |
3/4 | 26.7 | 2.9 | 1.89 | 20.9 | 2.40 |
1 | 33.4 | 3.4 | 2.79 | 26.6 | 3.55 |
1-1/4 | 42.2 | 3.6 | 3.78 | 35.0 | 4.81 |
1-1/2 | 48.3 | 3.7 | 4.52 | 40.9 | 5.76 |
2 | 60.3 | 3.9 | 6.07 | 52.5 | 7.73 |
2-1/2 | 73.0 | 5.2 | 9.62 | 62.6 | 12.26 |
3 | 88.9 | 5.5 | 12.59 | 77.9 | 16.04 |
4 | 114.3 | 6.0 | 17.92 | 102.3 | 22.83 |
5 | 141.3 | 6.6 | 24.89 | 128.1 | 31.72 |
6 | 168.3 | 7.1 | 32.22 | 154.1 | 41.06 |
8 | 219.1 | 8.2 | 49.24 | 202.7 | 62.71 |
10 | 273.0 | 9.3 | 70.68 | 254.4 | 90.01 |
12 | 323.9 | 9.5 | 87.68 | 304.9 | 111.7 |
Alloy Steel Forged Pipes (ASTM A182 F22)
Nominal Size (inches) | Outside Diameter (mm) | Wall Thickness (mm) | Weight per Meter (kg) | Internal Diameter (mm) | Cross-sectional Area (cm²) |
2 | 60.3 | 3.9 | 5.67 | 52.5 | 7.22 |
3 | 88.9 | 5.5 | 11.76 | 77.9 | 14.98 |
4 | 114.3 | 6.0 | 16.74 | 102.3 | 21.32 |
6 | 168.3 | 7.1 | 30.11 | 154.1 | 38.34 |
8 | 219.1 | 8.2 | 46.02 | 202.7 | 58.63 |
10 | 273.0 | 9.3 | 66.05 | 254.4 | 84.15 |
12 | 323.9 | 9.5 | 81.91 | 304.9 | 104.4 |
Material Properties and Engineering Excellence
Forged Pipe systems represent a critical component in industrial applications, offering exceptional mechanical properties that meet rigorous engineering standards. With tensile strength ranging from 415-585 MPa for carbon steel grades and temperature resistance capabilities extending from -29°C to 427°C (up to 816°C for stainless steel variants), these components deliver reliable performance across demanding operational environments. Manufacturing standards comply with international specifications including ASTM material requirements, ASME dimensional tolerances, and API performance standards, ensuring quality through comprehensive testing protocols such as hydrostatic pressure testing and non-destructive examination procedures.
Advanced B2B Services and Digital Procurement Solutions
Modern b2b services have transformed Forged Pipe procurement through advanced digital platforms like pipex.ai, which streamline inventory management, technical consultation, and logistics coordination for professional buyers. These sophisticated systems provide real-time inventory visibility, automated requisition workflows, and integrated supplier performance analytics, enabling procurement teams to optimize sourcing decisions through comprehensive cost analysis and delivery optimization. Combined with specialized handling requirements, custom packaging solutions, and value-added processing services including cutting, beveling, and surface preparation, today's supply chain platforms ensure seamless integration between manufacturing schedules and customer delivery requirements. This comprehensive approach to Forged Pipe Weight Chart in kg, mm, pdf specifications supports effective project execution, cost optimization, and structural analysis across complex industrial applications.
