Comprehensive GRP Valves Weight Chart
Ball Valves Weight Specifications
Size (mm) | Body Weight (kg) | Ball Weight (kg) | Stem Weight (kg) | Actuator Weight (kg) | Total Weight (kg) | Flange Rating | Wall Thickness |
15 | 0.8 | 0.1 | 0.2 | 1.1 | 2.2 | PN16 | 3.5mm |
20 | 1.0 | 0.15 | 0.25 | 1.3 | 2.7 | PN16 | 3.8mm |
25 | 1.2 | 0.2 | 0.3 | 1.5 | 3.2 | PN16 | 4.0mm |
32 | 1.6 | 0.25 | 0.35 | 2.1 | 4.3 | PN16 | 4.2mm |
40 | 2.1 | 0.3 | 0.4 | 2.8 | 5.6 | PN16 | 4.5mm |
50 | 2.8 | 0.4 | 0.5 | 3.7 | 7.4 | PN16 | 5.0mm |
65 | 4.2 | 0.6 | 0.7 | 5.8 | 11.3 | PN16 | 5.5mm |
80 | 5.8 | 0.8 | 0.9 | 7.9 | 15.4 | PN16 | 6.0mm |
100 | 8.4 | 1.2 | 1.3 | 11.5 | 22.4 | PN16 | 6.5mm |
125 | 12.7 | 1.8 | 1.9 | 17.8 | 34.2 | PN16 | 7.0mm |
150 | 18.3 | 2.6 | 2.8 | 25.7 | 49.4 | PN16 | 7.5mm |
200 | 28.9 | 4.1 | 4.4 | 41.2 | 78.6 | PN16 | 8.5mm |
250 | 42.7 | 6.2 | 6.8 | 62.8 | 118.5 | PN16 | 9.5mm |
300 | 58.3 | 8.7 | 9.4 | 86.1 | 162.5 | PN16 | 10.5mm |
Butterfly Valves Detailed Weight Chart
Size (mm) | Body Weight (kg) | Disc Weight (kg) | Shaft Weight (kg) | Seal Weight (kg) | Actuator Weight (kg) | Total Weight (kg) | Pressure Rating |
40 | 1.8 | 0.3 | 0.15 | 0.08 | 2.1 | 4.43 | PN10/16 |
50 | 2.1 | 0.4 | 0.18 | 0.12 | 2.6 | 5.30 | PN10/16 |
65 | 2.8 | 0.6 | 0.22 | 0.15 | 3.4 | 7.17 | PN10/16 |
80 | 3.6 | 0.8 | 0.28 | 0.19 | 4.3 | 9.17 | PN10/16 |
100 | 5.4 | 1.2 | 0.35 | 0.24 | 6.2 | 13.39 | PN10/16 |
125 | 8.1 | 1.8 | 0.45 | 0.32 | 9.1 | 19.77 | PN10/16 |
150 | 11.2 | 2.4 | 0.58 | 0.41 | 12.8 | 27.39 | PN10/16 |
200 | 18.7 | 3.8 | 0.78 | 0.62 | 21.4 | 45.30 | PN10/16 |
250 | 28.4 | 5.9 | 1.12 | 0.87 | 32.8 | 69.09 | PN10/16 |
300 | 39.2 | 8.4 | 1.54 | 1.18 | 46.3 | 96.62 | PN10/16 |
350 | 52.1 | 11.7 | 2.08 | 1.56 | 62.4 | 129.84 | PN10/16 |
400 | 67.8 | 15.8 | 2.74 | 2.08 | 81.2 | 169.62 | PN10/16 |
Advanced GRP Valve Construction and Digital Integration
Modern grp valves utilize advanced resin systems with continuous glass fiber reinforcement, optimizing strength-to-weight ratios while maintaining structural integrity. Leading manufacturers ensure their valve specifications meet international standards, with platforms like pipex.ai providing comprehensive databases of certified weight charts for project planning.
The reduced weight of grp valves significantly simplifies installation procedures and reduces equipment requirements, enabling single-person handling for smaller sizes and improving operational efficiency in elevated or confined spaces. Continuous advancement in composite materials technology promises even lighter valves without compromising performance, with digital platforms like pipex.ai ensuring latest weight specifications remain accessible to engineering professionals worldwide. As industry trends drive growing adoption across diverse applications, updated grp valves weight chart in kg, mm, pdf documentation continues to be essential for successful project execution and cost-effective system design.
