Seamless Pipes Weight Chart in Kg, Mm, PDF is a helpful resource for engineers, fabricators, and purchasers who require precise pipe weight information for planning and execution. seamless pipes, accurate weight data is essential for material selection, load calculations, and cost estimation. The downloadable PDF version guarantees that you always have the data when you need it, whether at the office or on-site. This chart facilitates your work by providing quick access to standard weights.
Comprehensive Seamless Pipes Weight Reference Guide
Nominal Size (mm) | External Diameter (mm) | Thickness (mm) | Unit Weight (kg/m) | 6m Length (kg) | 12m Length (kg) |
15 | 21.3 | 2.8 | 1.44 | 8.64 | 17.28 |
20 | 26.9 | 2.9 | 1.85 | 11.10 | 22.20 |
25 | 33.7 | 3.4 | 2.93 | 17.58 | 35.16 |
32 | 42.4 | 3.6 | 3.89 | 23.34 | 46.68 |
40 | 48.3 | 4.0 | 4.91 | 29.46 | 58.92 |
50 | 60.3 | 4.5 | 6.85 | 41.10 | 82.20 |
65 | 73.0 | 5.8 | 10.74 | 64.44 | 128.88 |
80 | 88.9 | 6.3 | 14.27 | 85.62 | 171.24 |
100 | 114.3 | 7.1 | 20.93 | 125.58 | 251.16 |
125 | 141.3 | 7.8 | 28.57 | 171.42 | 342.84 |
150 | 168.3 | 8.5 | 37.42 | 224.52 | 449.04 |
200 | 219.1 | 9.5 | 54.73 | 328.38 | 656.76 |
250 | 273.0 | 10.8 | 78.65 | 471.90 | 943.80 |
300 | 323.9 | 12.1 | 105.84 | 635.04 | 1270.08 |
Specialized Industrial Applications Weight Matrix
Application Category | Diameter Range (mm) | Typical Weight (kg/m) | Performance Factor |
Hydraulic Systems | 21.3 - 114.3 | 1.44 - 20.93 | High Pressure Rating |
Structural Framework | 141.3 - 323.9 | 28.57 - 105.84 | Load Distribution |
Process Industries | 168.3 - 273.0 | 37.42 - 78.65 | Corrosion Resistance |
Energy Transmission | 219.1 - 406.4 | 54.73 - 142.16 | Temperature Stability |
