5083 Aluminium Sheet Manufacturer in India Supplying Marine-Grade High-Strength Aluminium Sheets
Inox Steel India is one of the top 5083 Aluminium Sheet Manufacturers in India which produces high-quality aluminium sheets, renowned by their superb performance under seawater and severe conditions. 5083 aluminium sheet is used in marine structures, shipbuilding, pressure vessels, and transportation as well because it performs better in seawater and harsh climates. It is the best application in heavy-duty due to its non-heat-treatable composition that offers a high level of resistance to stress corrosion cracking.
5083 aluminium sheets that are available in various thicknesses and custom sizes are available in multiple thicknesses and sizes and are supplied by an excellent B2B platform to suit industrial needs. In structural applications that need superior machinability, it is common to use 6082 T6 Aluminium Sheet whereas in its fabrication versatility and moderate strength 6061 T6 Aluminium Sheet is mostly used.
Aluminium 5083 sheets maintain the mechanical strength at low temperature, and thus, they can be utilized in the demanding marine and offshore conditions, and 5052 Aluminium Sheet has moderate corrosion resistance requirements. The product range is used to assist in the construction of shipbuilding, offshore platforms, and heavy engineering projects, whereby the product range provides consistent quality and reliable supply as a trusted 5083 Aluminium Sheet Dealer In India.
Material & Grades of Aluminium Sheet
Several alloys and tempers of aluminium sheets are produced to meet the strength, corrosion and fabrication requirements. The grade used depends on the selection of the best one to attain the best performance and a long service life.
| Material | Grade / Standard | Temper | Thickness (mm) | Width (mm) | Typical Applications |
|---|---|---|---|---|---|
| Aluminium | EN AW-5083 | H111 / H321 | 1.5 – 50.0 | 1000 – 2500 | Marine, shipbuilding |
| Aluminium | EN AW-5052 | H32 | 0.5 – 6.0 | 1000 – 2000 | Fuel tanks, panels |
| Aluminium | EN AW-6061 | T6 | 1.0 – 25.0 | 1000 – 2000 | Structural components |
| Aluminium | EN AW-6082 | T6 | 1.0 – 40.0 | 1000 – 2000 | Load-bearing structures |
| Aluminium | EN AW-7075 | T6 | 0.8 – 12.0 | 1000 – 1500 | Aerospace parts |
Key Product Features & Advantages
- Very good resistance to corrosion in the seas.
- Strongness and high durability.
- High welding and bending ability.
- Appropriate in low temperature applications.
- Standard and custom-cut models
- Sized in standard and custom-cut.
- Good in building ships and offshore engineering application.
5083 Aluminium Sheets Chemical Properties:-
| Al | Cu | Mn | Cr | Si | Fe | Ti | Mg | Zn | Other Each | Others Total |
| Bal | 0.10 max | 0.40 / 1.0 | 0.05 / 0.25 | 0.40 max | 0.40 max | 0.15 max | 4.0 / 4.90 | 0.25 max | 0.05 max | 0.15 max |
5083 Aluminium Sheets Mechanical Properties:-
| Tensile Strength | Hardness Brinell | Proof Stress | Elongation |
| 275 – 350 MPa | 75 HB | 125 Min MPa | 12 Min % |
5083 Aluminium Sheets Equivalent Grades:-
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlMg4,5Mn0,7 | AG4,5MC | 3.3547 | A95083 | AlMg4,5Mn0,7 | 5083 | AlMg4,5Mn |
