Premium Bend Pipe Fittings Manufacturer–long Radius & Short Radius Pipe Bends

Name: Premium Bend Pipe Fittings Manufacturer–long Radius & Short Radius Pipe Bends
Brand: Neminox Steel & Engineering Co
Availability: InStock
Rating: 4 (1 reviews)

Specification Details
Specifications	Astm, Asme, Din, Nf, Jis, En, Ios
Size Range	1/2"nb To 48"nb, 1/2"nb, 48"nb
Dimension	Asme/ansi B16.9, Asme B16.28, Mss Sp 43

Bend Pipe Fittings Manufacturer in India

Neminox Steel & Engineering Co. is one of the largest Bend Pipe Fittings Manufacturers in India. Bends are crucial fittings used in piping systems, which allow the change of direction without hindering the flow of liquid. Bend pipe fittings differ from elbow fittings in that bends create a smooth curve while elbows make an abrupt turn. These Pipe fittings are available in various radii, commonly 3D, 5D, or custom specifications, offering flexibility in pipeline routing and design.

As a reputed supplier of bend pipe fittings in India, we ensure the supply of top-notch quality fittings available at reasonable prices. Made from materials such as carbon steel, stainless steel, and alloy steel, our range of fittings caters to the different needs of industries like oil & gas, petrochemicals, and power generation industry. The use of specific materials ensures strength, resistance to corrosion, and capability of bearing high pressure and high temperature conditions. Being a reputable B2B supplier, we offer customized solutions, excellent packaging for exportation, as well as curved shape of our fittings that help improve flow rate while reducing turbulence.

Bend Pipe Fittings – Dimensional & Application Guide

The table below presents typical dimensional information for Bend Pipe Fittings used in industrial piping systems. These fittings are manufactured in accordance with recognized industry standards and are designed to provide smooth directional changes in pipelines. Dimensions may vary depending on material grade, wall thickness, pressure rating, and manufacturing specifications.

Bend Pipe Fittings

Nominal Size (NB)	Bend Radius (mm)	Center to End (mm)	Wall Thickness (mm)	Approx. Weight (Kg)
½" (15 NB)	38	25	2.0	0.15
¾" (20 NB)	45	30	2.3	0.22
1" (25 NB)	57	38	2.6	0.35
1½" (40 NB)	76	57	3.0	0.65
2" (50 NB)	95	76	3.2	1.10
3" (80 NB)	145	114	4.0	2.50
4" (100 NB)	190	152	4.5	4.20
6" (150 NB)	285	229	5.0	8.80
8" (200 NB)	380	305	6.3	15.50

About Bend Pipe Fittings

Bend pipe fittings are designed in a way that will be able to effectively guide the flow of media such as gases, liquids, and other processing substances without causing any pressure loss and turbulence. Made using superior materials, our fittings provide high levels of strength, precision in terms of dimensions, and resistance against corrosion.Applicable in different industries including oil and gas, chemical processing, power generation, water treatment, and construction industries, bend pipe fittings allow the creation of durable piping systems. The fittings are subject to quality assurance in order to ensure their consistent performance and secure installation. We can also manufacture custom-made fittings to fit your needs.
