In industrial and construction supply chains, bolts are everywhere. From structural steelwork to machinery, these essential components are critical to integrity, performance, and safety. But when it comes to bulk procurement, there’s one detail buyers often overlook — weight.
Accurate bolt weight data isn’t just useful — it’s a necessity for calculating shipping costs, planning storage, and ensuring regulatory compliance. That’s why more professionals rely on a bolt weight chart to manage large-scale orders efficiently. And for the smartest sourcing? Tools like a digital B2B portal such as Pipex.ai are changing the game.
Detailed Bolt Weight Chart
Below is a bolt weight chart in kg that includes several common types and sizes. This chart represents average weights for bolts made of standard carbon steel and calculated per 100 pieces.
Bolt Type | Size (mm) | Avg. Weight (kg/100 pcs) | Common Application |
Hex Bolt | M6 x 20 | 1.2 | Light mechanical fastening |
Hex Bolt | M8 x 40 | 4.5 | Automotive, framing |
Hex Bolt | M10 x 50 | 6.5 | Structural and general use |
Hex Bolt | M12 x 100 | 17.2 | Heavy-duty anchoring and supports |
Hex Bolt | M16 x 150 | 34.2 | Large machinery and infrastructure |
Carriage Bolt | M10 x 100 | 12.0 | Timber and steel jointing |
Eye Bolt | M12 x 150 | 24.5 | Lifting and rigging |
U-Bolt | M10 x 70 | 9.6 | Pipe support systems |
Note: Weights may vary based on material grade and thread length. Always verify with your supplier for exact specifications.
This chart not only assists with freight estimates but also helps calculate order quantities, confirm load limits, and ensure smooth delivery and storage operations.
Thread, d M30 M36 M39 M42 M45 M48 M56 M64 Nominal length, l Weight* in kg/100 pcs., with 7.85 kg/dm3 70 64,4 80 69,9 110,5 90 75,5 118,49 100 81,0 126,48 110 86,6 134,5 161,1 120 92,1 142,5 170,5 200,6 238,6 130 97,7 150,5 179,9 211,5 251,1 294,7 140 103,2 158,4 189,3 222,4 263,6 308,9 431,4 150 108,8 166,4 198,6 233,3 276,1 323,1 450,7 608,0 160 114,3 174,4 208,0 244,1 288,6 337,3 470,1 633,2 170 119,9 182,4 217,4 255,0 301,1 351,5 489,4 658,5 180 125,4 190,4 226,8 265,9 313,5 365,8 508,7 683,7 190 131,0 198,4 236,2 276,8 326,0 380,0 528,1 709,0 200 136,5 206,4 245,5 287,6 338,5 394,2 547,4 734,2 210 142,1 214,4 254,9 298,5 351,0 408,4 566,8 759,5 220 147,6 222,4 264,3 309,4 363,5 422,6 586,1 784,7 230 153,2 230,4 273,7 320,3 376,0 436,8 605,4 810,0 240 158,7 238,3 283,0 331,1 388,5 451,0 624,8 835,3 250 164,3 246,3 292,4 342,0 400,9 465,2 644,1 860,5 260 169,8 254,3 301,8 352,9 413,4 479,4 663,4 885,8 270 175,4 262,3 311,2 363,8 425,9 493,6 682,8 911,0 280 180,9 270,3 320,6 374,6 438,4 507,8 702,1 936,3 290 186,5 278,3 329,9 385,5 450,9 522,0 721,4 961,5 300 192,0 286,3 339,3 396,4 463,4 536,2 740,8 986,8 310 197,6 294,3 348,7 407,3 475,9 550,4 760,1 1012,0 320 203,1 302,3 358,1 418,1 488,3 564,6 779,4 1037,3 330 208,7 310,3 367,4 429,0 500,8 578,8 798,8 1062,5 340 214,2 318,2 376,8 439,9 513,3 593,0 818,1 1087,8 350 219,8 326,2 386,2 450,8 525,8 607,2 837,4 1113,0 360 225,3 334,2 395,6 461,6 538,3 621,4 856,8 1138,3 370 230,9 342,2 404,9 472,5 550,8 635,6 876,1 1163,5 380 236,4 350,2 414,3 483,4 563,2 649,9 895,4 1188,8 390 242,0 358,2 423,7 494,3 575,7 664,1 914,8 1214,1 400 247,5 366,2 433,1 505,1 588,2 678,3 934,1 1239,3 410 253,1 374,2 442,5 516,0 600,7 692,5 953,4 1264,6 420 258,6 382,2 451,8 526,9 613,2 706,7 972,8 1289,8 430 264,2 390,2 461,2 537,8 625,7 720,9 992,1 1315,1 440 269,7 398,2 470,6 548,7 638,2 735,1 1011,4 1340,3 450 275,3 406,1 480,0 559,5 650,6 749,3 1030,8 1365,6 460 280,8 414,1 489,3 570,4 663,1 763,5 1050,1 1390,8 470 286,4 422,1 498,7 581,3 675,6 777,7 1069,5 1416,1 480 291,9 430,1 508,1 592,2 688,1 791,9 1088,8 1441,3 490 297,5 438,1 517,5 603,0 700,6 806,1 1108,1 1466,6 500 303,0 446,1 526,9 613,9 713,1 820,3 1127,5 1491,8 + 2 HV-washers 12,6 21,2 26,1 41,4 50,0 58,8 94,4 109,4 + 1 HV-nut 26,2 46,0 69,9 81,8 97,2 116,9 170,4 231,7 Σ 38,8 67,2 96,0 123,2 147,2 175,7 264,8 341,1
Thread, d | M30 | M36 | M39 | M42 | M45 | M48 | M56 | M64 |
Nominal length, l | Weight* in kg/100 pcs., with 7.85 kg/dm3 | |||||||
70 | 64,4 | |||||||
80 | 69,9 | 110,5 | ||||||
90 | 75,5 | 118,49 | ||||||
100 | 81,0 | 126,48 | ||||||
110 | 86,6 | 134,5 | 161,1 | |||||
120 | 92,1 | 142,5 | 170,5 | 200,6 | 238,6 | |||
130 | 97,7 | 150,5 | 179,9 | 211,5 | 251,1 | 294,7 | ||
140 | 103,2 | 158,4 | 189,3 | 222,4 | 263,6 | 308,9 | 431,4 | |
150 | 108,8 | 166,4 | 198,6 | 233,3 | 276,1 | 323,1 | 450,7 | 608,0 |
160 | 114,3 | 174,4 | 208,0 | 244,1 | 288,6 | 337,3 | 470,1 | 633,2 |
170 | 119,9 | 182,4 | 217,4 | 255,0 | 301,1 | 351,5 | 489,4 | 658,5 |
180 | 125,4 | 190,4 | 226,8 | 265,9 | 313,5 | 365,8 | 508,7 | 683,7 |
190 | 131,0 | 198,4 | 236,2 | 276,8 | 326,0 | 380,0 | 528,1 | 709,0 |
200 | 136,5 | 206,4 | 245,5 | 287,6 | 338,5 | 394,2 | 547,4 | 734,2 |
210 | 142,1 | 214,4 | 254,9 | 298,5 | 351,0 | 408,4 | 566,8 | 759,5 |
220 | 147,6 | 222,4 | 264,3 | 309,4 | 363,5 | 422,6 | 586,1 | 784,7 |
230 | 153,2 | 230,4 | 273,7 | 320,3 | 376,0 | 436,8 | 605,4 | 810,0 |
240 | 158,7 | 238,3 | 283,0 | 331,1 | 388,5 | 451,0 | 624,8 | 835,3 |
250 | 164,3 | 246,3 | 292,4 | 342,0 | 400,9 | 465,2 | 644,1 | 860,5 |
260 | 169,8 | 254,3 | 301,8 | 352,9 | 413,4 | 479,4 | 663,4 | 885,8 |
270 | 175,4 | 262,3 | 311,2 | 363,8 | 425,9 | 493,6 | 682,8 | 911,0 |
280 | 180,9 | 270,3 | 320,6 | 374,6 | 438,4 | 507,8 | 702,1 | 936,3 |
290 | 186,5 | 278,3 | 329,9 | 385,5 | 450,9 | 522,0 | 721,4 | 961,5 |
300 | 192,0 | 286,3 | 339,3 | 396,4 | 463,4 | 536,2 | 740,8 | 986,8 |
310 | 197,6 | 294,3 | 348,7 | 407,3 | 475,9 | 550,4 | 760,1 | 1012,0 |
320 | 203,1 | 302,3 | 358,1 | 418,1 | 488,3 | 564,6 | 779,4 | 1037,3 |
330 | 208,7 | 310,3 | 367,4 | 429,0 | 500,8 | 578,8 | 798,8 | 1062,5 |
340 | 214,2 | 318,2 | 376,8 | 439,9 | 513,3 | 593,0 | 818,1 | 1087,8 |
350 | 219,8 | 326,2 | 386,2 | 450,8 | 525,8 | 607,2 | 837,4 | 1113,0 |
360 | 225,3 | 334,2 | 395,6 | 461,6 | 538,3 | 621,4 | 856,8 | 1138,3 |
370 | 230,9 | 342,2 | 404,9 | 472,5 | 550,8 | 635,6 | 876,1 | 1163,5 |
380 | 236,4 | 350,2 | 414,3 | 483,4 | 563,2 | 649,9 | 895,4 | 1188,8 |
390 | 242,0 | 358,2 | 423,7 | 494,3 | 575,7 | 664,1 | 914,8 | 1214,1 |
400 | 247,5 | 366,2 | 433,1 | 505,1 | 588,2 | 678,3 | 934,1 | 1239,3 |
410 | 253,1 | 374,2 | 442,5 | 516,0 | 600,7 | 692,5 | 953,4 | 1264,6 |
420 | 258,6 | 382,2 | 451,8 | 526,9 | 613,2 | 706,7 | 972,8 | 1289,8 |
430 | 264,2 | 390,2 | 461,2 | 537,8 | 625,7 | 720,9 | 992,1 | 1315,1 |
440 | 269,7 | 398,2 | 470,6 | 548,7 | 638,2 | 735,1 | 1011,4 | 1340,3 |
450 | 275,3 | 406,1 | 480,0 | 559,5 | 650,6 | 749,3 | 1030,8 | 1365,6 |
460 | 280,8 | 414,1 | 489,3 | 570,4 | 663,1 | 763,5 | 1050,1 | 1390,8 |
470 | 286,4 | 422,1 | 498,7 | 581,3 | 675,6 | 777,7 | 1069,5 | 1416,1 |
480 | 291,9 | 430,1 | 508,1 | 592,2 | 688,1 | 791,9 | 1088,8 | 1441,3 |
490 | 297,5 | 438,1 | 517,5 | 603,0 | 700,6 | 806,1 | 1108,1 | 1466,6 |
500 | 303,0 | 446,1 | 526,9 | 613,9 | 713,1 | 820,3 | 1127,5 | 1491,8 |
+ 2 HV-washers | 12,6 | 21,2 | 26,1 | 41,4 | 50,0 | 58,8 | 94,4 | 109,4 |
+ 1 HV-nut | 26,2 | 46,0 | 69,9 | 81,8 | 97,2 | 116,9 | 170,4 | 231,7 |
Σ | 38,8 | 67,2 | 96,0 | 123,2 | 147,2 | 175,7 | 264,8 | 341,1 |
