Allen bolts weight chart in kg, mm, pdf resources are essential for precision manufacturing projects. These socket head cap screws require accurate weight measurements to optimize material costs and determine structural load requirements across industrial applications.


Comprehensive Allen Bolts Weight Chart in kg and mm Specifications

Comprehensive Allen Bolts Weight Chart Table

Thread Size (mm)

Length (mm)

Head Diameter (mm)

Socket Size (mm)

Weight (grams)

Weight (kg)

Pieces per kg

M3

8

5.5

2.5

0.85

0.00085

1,176

M3

10

5.5

2.5

1.02

0.00102

980

M3

12

5.5

2.5

1.18

0.00118

847

M3

16

5.5

2.5

1.45

0.00145

690

M3

20

5.5

2.5

1.78

0.00178

562

M3

25

5.5

2.5

2.15

0.00215

465

M4

8

7.0

3.0

1.65

0.00165

606

M4

10

7.0

3.0

1.95

0.00195

513

M4

12

7.0

3.0

2.25

0.00225

444

M4

16

7.0

3.0

2.85

0.00285

351

M4

20

7.0

3.0

3.45

0.00345

290

M4

25

7.0

3.0

4.15

0.00415

241

M4

30

7.0

3.0

4.85

0.00485

206

M5

10

8.5

4.0

3.25

0.00325

308

M5

12

8.5

4.0

3.85

0.00385

260

M5

16

8.5

4.0

4.75

0.00475

211

M5

20

8.5

4.0

5.65

0.00565

177

M5

25

8.5

4.0

6.85

0.00685

146

M5

30

8.5

4.0

8.05

0.00805

124

M5

35

8.5

4.0

9.25

0.00925

108

M5

40

8.5

4.0

10.45

0.01045

96

M6

12

10.0

5.0

6.85

0.00685

146

M6

16

10.0

5.0

8.25

0.00825

121

M6

20

10.0

5.0

9.85

0.00985

102

M6

25

10.0

5.0

11.95

0.01195

84

M6

30

10.0

5.0

14.05

0.01405

71

M6

35

10.0

5.0

16.15

0.01615

62

M6

40

10.0

5.0

18.25

0.01825

55

M6

50

10.0

5.0

22.45

0.02245

45

M8

16

13.0

6.0

16.75

0.01675

60

M8

20

13.0

6.0

18.95

0.01895

53

M8

25

13.0

6.0

22.75

0.02275

44

M8

30

13.0

6.0

26.55

0.02655

38

M8

35

13.0

6.0

30.35

0.03035

33

M8

40

13.0

6.0

34.15

0.03415

29

M8

50

13.0

6.0

41.75

0.04175

24

M8

60

13.0

6.0

49.35

0.04935

20

M10

20

16.0

8.0

35.85

0.03585

28

M10

25

16.0

8.0

42.25

0.04225

24

M10

30

16.0

8.0

48.65

0.04865

21

M10

35

16.0

8.0

55.05

0.05505

18

M10

40

16.0

8.0

61.45

0.06145

16

M10

50

16.0

8.0

74.25

0.07425

13

M10

60

16.0

8.0

87.05

0.08705

11

M12

25

18.0

10.0

68.45

0.06845

15

M12

30

18.0

10.0

78.25

0.07825

13

M12

35

18.0

10.0

88.05

0.08805

11

M12

40

18.0

10.0

97.85

0.09785

10

M12

50

18.0

10.0

117.45

0.11745

9

M12

60

18.0

10.0

137.05

0.13705

7

M12

70

18.0

10.0

156.65

0.15665

6


Extended Size Allen Bolts Weight Chart

Thread Size (mm)

Length (mm)

Head Diameter (mm)

Socket Size (mm)

Weight (grams)

Weight (kg)

Pieces per kg

M14

30

21.0

12.0

125.85

0.12585

8

M14

40

21.0

12.0

155.25

0.15525

6

M14

50

21.0

12.0

184.65

0.18465

5

M14

60

21.0

12.0

214.05

0.21405

5

M16

35

24.0

14.0

195.75

0.19575

5

M16

40

24.0

14.0

218.25

0.21825

5

M16

50

24.0

14.0

263.25

0.26325

4

M16

60

24.0

14.0

308.25

0.30825

3

M20

40

30.0

17.0

425.85

0.42585

2

M20

50

30.0

17.0

512.25

0.51225

2

M20

60

30.0

17.0

598.65

0.59865

2

M20

80

30.0

17.0

771.45

0.77145

1
