Fastener Type | Diameter (mm) | Length (mm) | Weight per Unit (g) | Weight - 1000 pcs (kg) | Material Grade |
Phillips Head Screw | M4 | 16 | 1.8 | 1.80 | Steel 4.6 |
Phillips Head Screw | M5 | 20 | 3.2 | 3.20 | Steel 4.6 |
Phillips Head Screw | M6 | 25 | 5.1 | 5.10 | Steel 4.6 |
Carriage Bolt | M8 | 30 | 11.4 | 11.40 | Steel 4.6 |
Carriage Bolt | M10 | 40 | 18.7 | 18.70 | Steel 4.6 |
Carriage Bolt | M12 | 50 | 28.9 | 28.90 | Steel 4.6 |
Wing Nut | M6 | - | 3.4 | 3.40 | Steel 4.6 |
Wing Nut | M8 | - | 6.8 | 6.80 | Steel 4.6 |
Wing Nut | M10 | - | 12.5 | 12.50 | Steel 4.6 |
T-Bolt | M8 | 35 | 14.2 | 14.20 | Steel 8.8 |
T-Bolt | M10 | 45 | 23.6 | 23.60 | Steel 8.8 |
T-Bolt | M12 | 55 | 36.8 | 36.80 | Steel 8.8 |
Eye Bolt | M8 | 50 | 19.3 | 19.30 | Steel 4.6 |
Eye Bolt | M10 | 60 | 31.7 | 31.70 | Steel 4.6 |
Eye Bolt | M12 | 70 | 47.2 | 47.20 | Steel 4.6 |
U-Bolt | M8 | 80x40 | 45.6 | 45.60 | Steel 4.6 |
U-Bolt | M10 | 100x50 | 72.3 | 72.30 | Steel 4.6 |
U-Bolt | M12 | 120x60 | 105.8 | 105.80 | Steel 4.6 |
Lock Washer | M6 | - | 0.7 | 0.70 | Spring Steel |
Lock Washer | M8 | - | 1.3 | 1.30 | Spring Steel |
Lock Washer | M10 | - | 2.1 | 2.10 | Spring Steel |
Lock Washer | M12 | - | 3.2 | 3.20 | Spring Steel |
Thumb Screw | M6 | 20 | 4.9 | 4.90 | Steel 4.6 |
Thumb Screw | M8 | 25 | 8.7 | 8.70 | Steel 4.6 |
Thumb Screw | M10 | 30 | 14.5 | 14.50 | Steel 4.6 |
Set Screw | M4 | 8 | 0.9 | 0.90 | Steel 45H |
Set Screw | M5 | 10 | 1.6 | 1.60 | Steel 45H |
Set Screw | M6 | 12 | 2.8 | 2.80 | Steel 45H |
Set Screw | M8 | 16 | 5.4 | 5.40 | Steel 45H |
Rivet | 4.8 | 12 | 1.2 | 1.20 | Aluminum |
Rivet | 6.4 | 16 | 2.8 | 2.80 | Aluminum |
Rivet | 8.0 | 20 | 4.9 | 4.90 | Aluminum |
Hex Bolt Weight Chart (per 100 pieces in kg – Mild Steel)
| Diameter (mm) | Length (mm) | Weight (kg/100 pcs) |
|---|---|---|
| M6 | 20 | 1.50 kg |
| M8 | 30 | 3.20 kg |
| M10 | 50 | 6.80 kg |
| M12 | 75 | 11.60 kg |
| M16 | 100 | 20.50 kg |
| M20 | 150 | 36.80 kg |
Hex Nut Weight Chart (per 1000 pieces in kg – Mild Steel)
| Size (mm) | Weight (kg/1000 pcs) |
|---|---|
| M6 | 5.00 kg |
| M8 | 8.50 kg |
| M10 | 13.60 kg |
| M12 | 19.20 kg |
| M16 | 30.00 kg |
| M20 | 48.00 kg |
