In the industrial sector, especially in the plumbing, oil and gas, and construction industries, pipe fittings play a critical role in joining, redirecting, and managing the flow of fluids. One of the essential aspects that buyers and suppliers in the India B2B market focus on is the pipe fittings weight chart in kg pdf. This chart is a vital reference that helps businesses calculate transportation costs, estimate material usage, and plan for inventory and logistics. For stakeholders in the India B2B marketplace, understanding this chart is key to making informed purchase decisions.
Here is an example of how a weight chart may look for stainless steel fittings:
Fitting Type | Size (inches) | Weight (kg) |
Elbow 90° | 1 | 0.25 |
Elbow 90° | 2 | 0.75 |
Tee | 2 | 1.10 |
Reducer | 3 x 2 | 1.45 |
Cap | 2 | 0.60 |
Pipe Fittings Weight Chart (Approximate in Kilograms)
Fitting Type | Size (inches) | Weight (kg/piece) |
Elbow 90° (Long Radius) | 1/2" | 0.15 |
1" | 0.40 | |
2" | 1.50 | |
4" | 5.60 | |
6" | 11.50 | |
Elbow 45° (Long Radius) | 1/2" | 0.12 |
1" | 0.35 | |
2" | 1.20 | |
4" | 4.80 | |
6" | 9.80 | |
Tee | 1/2" | 0.25 |
1" | 0.60 | |
2" | 2.20 | |
4" | 7.90 | |
6" | 15.20 | |
Reducer (Concentric) | 2" x 1" | 0.80 |
4" x 2" | 2.90 | |
6" x 4" | 5.20 | |
Cap | 1" | 0.40 |
2" | 1.30 | |
4" | 4.90 | |
6" | 9.50 | |
Flange (WNRF) | 2" | 2.70 |
4" | 6.80 | |
6" | 12.50 |
