Weld Neck Flange Weight Chart In Kg Mm Pdf: A Complete Guide

Author: Mustafa

June 20, 2025

Weld neck flange weight chart in kg mm pdf

Weld neck flange weight chart in kg mm pdf


Weld neck flange weight chart in KG, MM, PDF is an essential reference tool for engineers, piping designers, and procurement teams working with high-pressure and high-temperature pipe systems. Weld neck flanges are designed with a long tapered hub that provides reinforcement and allows smooth flow through pipelines. Available in a range of pressure ratings (Class 150 to 2500) and sizes (in inches and mm), their weight varies depending on material (carbon steel, stainless steel, alloy steel) and dimensions. Accurate weight data helps in shipping, load calculation, and layout planning. Having this chart in downloadable PDF format makes it easy to access and share across project teams.


Detailed Weld Neck Flange Weight Specifications

NPS (inches)

Outside Dia (mm)

Hub Dia (mm)

Thickness (mm)

Bore (mm)

Weight 150# (kg)

Weight 300# (kg)

Weight 600# (kg)

1/2

88.9

21.3

11.2

15.7

0.54

0.68

0.91

3/4

98.6

26.7

12.7

20.8

0.68

0.86

1.13

1

108.0

33.4

14.2

26.6

0.86

1.09

1.45

1-1/4

117.5

42.2

15.7

35.1

1.13

1.36

1.81

1-1/2

127.0

48.3

17.5

40.9

1.36

1.68

2.27

2

152.4

60.3

19.1

52.5

1.95

2.50

3.40

2-1/2

177.8

73.0

22.4

62.7

2.95

3.86

5.22

3

190.5

88.9

23.9

77.9

3.63

4.77

6.58

4

228.6

114.3

23.9

102.3

5.44

7.26

9.98

5

254.0

141.3

23.9

128.2

6.80

9.07

13.61

6

279.4

168.3

25.4

154.1

8.39

11.34

16.78

8

342.9

219.1

28.4

202.7

13.61

18.14

27.22

10

406.4

273.1

30.2

254.5

19.95

27.22

42.18

12

482.6

323.9

31.8

304.8

28.12

38.10

61.69

14

533.4

355.6

34.9

333.4

34.47

47.17

77.11

16

596.9

406.4

36.6

381.0

43.09

58.97

97.98

18

635.0

457.2

39.6

428.6

51.71

70.31

117.93

20

698.5

508.0

42.9

477.8

65.32

88.45

149.69

24

812.8

609.6

47.6

574.7

90.72

124.74

213.19


Weld Neck Flange Weight Chart – ASME B16.5 Class 150 (in KG)

Size (Inch) Outside Diameter (mm) Approx. Weight (kg)
1/2" 90 1.80 kg
1" 110 2.90 kg
2" 150 5.40 kg
3" 190 8.50 kg
4" 230 12.00 kg
6" 280 20.00 kg
8" 345 30.50 kg
10" 405 45.00 kg
