Flat Bars are also very strong, durable and versatile making them find a wide use in industrial, construction and fabrication activities. The bars are produced in high precision to maintain uniform thickness, good surface finish and uniform mechanical properties. The Flat Bars are normally used in structures, supporting construction, base plates, and the overall engineering projects in which reliability and performance are paramount.
Nova steel Corporation is a reputable manufacturer of Flat bars with good quality steel products that are internationally accepted. Since the company has a very high presence in the B2BMarket, it specializes in delivering the quality Flat Bars that are in line with the various industrial needs. Their values of quality control, prompt delivery, and customer satisfaction make them a good choice when global consumers are willing to find reliable solutions of steel.
Besides Flat Bars, the firm has other products like Stainless Steel Hex Bar that is widely used in fasteners, shafts, and precision components. As a result of strategic B2BBranding, the organisation has thus managed to build on its reputation through offering lasting products, fair prices, and reliable performance to enable the businesses to realize the sustainability of their operations.
Flat Bar Weight Chart (Stainless Steel)
The Flat Bar weight chart assists customers and the engineers to determine the precise weight per meter in terms of width and thickness. This is required in estimating the requirements of materials, the cost of transportation and the load bearing capacity in structural and fabrication. The formula given can be easily customized to non standard sizes.
Weight Formula:
Weight (kg/m) = Width (mm) × Thickness (mm) × 0.00793
| Width (mm) | Thickness (mm) | Weight (kg/m) |
|---|---|---|
| 25 | 5 | 0.99 |
| 30 | 5 | 1.19 |
| 40 | 5 | 1.59 |
| 50 | 5 | 1.98 |
| 25 | 6 | 1.19 |
| 30 | 6 | 1.43 |
| 40 | 6 | 1.90 |
| 50 | 6 | 2.38 |
| 50 | 8 | 3.17 |
| 65 | 8 | 4.12 |
| 75 | 10 | 5.95 |
| 100 | 10 | 7.93 |
Chemical Composition of Stainless Steel Flat Bar (Grade 304)
| Element | Composition (%) |
|---|---|
| Carbon (C) | ≤ 0.08 |
| Manganese (Mn) | ≤ 2.00 |
| Silicon (Si) | ≤ 1.00 |
| Chromium (Cr) | 18.00 – 20.00 |
| Nickel (Ni) | 8.00 – 10.50 |
| Phosphorus (P) | ≤ 0.045 |
| Sulfur (S) | ≤ 0.030 |
| Iron (Fe) | Balance |
The flat bar is made strong and workable with the help of mechanical composition. The tensile strength and yield strength is high to provide reliability when subjected to heavy loads and the elongation is good to facilitate easy fabrication, bending and welding. These characteristics render Stainless Steel Flat Bars wanted in the construction, machinery, industrial equipment, and structural utilities.
Mechanical Composition of Stainless Steel Flat Bar (Grade 304)
| Property | Value |
|---|---|
| Tensile Strength | ≥ 515 MPa |
| Yield Strength (0.2% Offset) | ≥ 205 MPa |
| Elongation | ≥ 40% |
| Hardness (Brinell) | ≤ 201 HB |
| Density | 7.93 g/cm³ |
