Hastelloy C22 Plates Manufacturer In India Supplying Astm B575 / Asme Sb575 Standard Plates For Chemical Processing
| Plate Standards | Astm A240, / Asme Sa240 |
|---|---|
| Material Grades | 405, 436l, 409, 441, 409l, 410, 446, 430ti, 410s, 409m, 415, 416, 410db, 430, 420, 431, 439, 436 |
| Surface | Embossed, 2d, 2b, Ba, Hair Line, No.1, No.4, 8k, Brush, No.8, Sand Blast, Mirror, Checkered, Etc, Etching |
| Finish | Ba No(8), 2d, 2b, Hot Rolled Plate (hr), Satin (met With Plastic Coated), Cold Rolled Plate (cr) |
Hastelloy C22 Plates Manufacturer in India Delivering Export-Quality Plates Conforming to ASTM, ASME & EN Standards
United Stainless LLP is a prominent Hastelloy C22 Plate Manufacturer in India, which provides high-quality nickel-chromium-molybdenum alloy plates designed with the best ability to resist pitting, crevice corrosion, and stress corrosion cracking. Hastelloy C22 Plates are widely deployed in chemical processing, pharmaceutical production, pollution control and heat exchanger applications with high standards of corrosion protection being essential.
Hastelloy C22 Plates can be purchased via a reputable B2B marketplace and are available in large variety of size and thickness to fit any project. These are plates included in a total of a collection of Hastelloy Plates with other related grades like Hastelloy B2 Plates and Hastelloy C276 Plates chosen depending on the application demands of various chemical and thermal performance qualities.
Hastelloy C22 plates are highly fabricable, highly weldable and stable over the long term use in hostile service conditions. Being a dependable Hastelloy C22 Plate Supplier In India, the products are prepared to meet international quality requirements and well tested to achieve stable mechanical characteristics and corrosion resistance in various challenging operating conditions.
Material & Grades of Hastelloy C22 Plates
Hastelloy C22 Plates come in standardized grade that can be used in critical industrial services.| Material | Grade / Standard | UNS No. | Thickness (mm) | Width (mm) | Typical Applications |
|---|---|---|---|---|---|
| Hastelloy | C22 | N06022 | 1.0 – 50.0 | 1000 – 2000 | Chemical processing |
| Hastelloy | B2 | N10665 | 2.0 – 50.0 | 1000 – 2000 | Reducing environments |
| Hastelloy | C276 | N10276 | 2.0 – 60.0 | 1000 – 2000 | Pollution control |
| Hastelloy | X | N06002 | 2.0 – 50.0 | 1000 – 2000 | Petrochemical plants |
Key Features & Advantages
- Exceptional resistance to localized corrosion
- High mechanical strength
- Excellent weldability
- Good formability
- Reliable performance in harsh environments
- Custom-cut sizes available
Hastelloy C22 Plates Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | EN | OR |
| Hastelloy C22 | 2.4602 | N06022 | NW 6022 | – | NiCr21Mo14W | – |
Chemical Composition Of Hastelloy Alloy C22 Plate
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| C22 | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.50 max | 50.015 min* | 20.00 – 22.50 | 2.00 – 6.00 | 12.50 – 14.50 | 0.02 max |
Alloy C22 Plate Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
Type of Sub-products
Hot Rolled Hastelloy C22 Plates Hot Rolled Hastelloy C22 Plates
Processed at high temperature; thicker, rougher surface; used in structural and industrial applications.
Cold Rolled Hastelloy C22 Plates Cold Rolled Hastelloy C22 Plates
Rolled at room temperature; smooth finish and tighter tolerances; ideal for precision applications.
