Understanding MS Angle Weight Charts
Mild Steel (MS) angles are one of the most commonly used structural steel products in construction, fabrication, and industrial applications. They come in L-shaped cross-sections and are measured by the lengths of the two legs and their thickness. Understanding MS Angle weight charts is crucial for project planning, material estimation, and structural design. These charts show the approximate weight of MS angles per meter, based on their dimensions in millimeters (mm). The weight is usually listed in kilograms (kg), helping engineers, buyers, and fabricators quickly determine the load and cost of materials.
MS angles are identified by their leg length and thickness – for example, a 50x50x6 mm angle has two 50 mm legs and a 6 mm thickness. The weight is calculated per meter and depends on the steel density (usually 7.85 gm/cm³). These charts are also useful for optimizing inventory, reducing waste, and ensuring accurate delivery. For your convenience, we’ve included a printable PDF version of the chart at the end.
MS Angle Weight Chart (in KG per Meter)
Size (mm) | Thickness (mm) | Weight (kg/m) |
25 x 25 | 3 | 1.10 |
25 x 25 | 5 | 1.78 |
30 x 30 | 3 | 1.34 |
30 x 30 | 5 | 2.19 |
35 x 35 | 5 | 2.60 |
40 x 40 | 5 | 3.01 |
45 x 45 | 5 | 3.43 |
50 x 50 | 5 | 3.84 |
50 x 50 | 6 | 4.56 |
60 x 60 | 6 | 5.56 |
65 x 65 | 6 | 6.08 |
70 x 70 | 6 | 6.60 |
75 x 75 | 6 | 7.12 |
80 x 80 | 6 | 7.63 |
90 x 90 | 6 | 8.65 |
100 x 100 | 6 | 9.67 |
100 x 100 | 8 | 12.70 |
110 x 110 | 10 | 17.40 |
130 x 130 | 10 | 20.64 |
150 x 150 | 10 | 23.88 |
150 x 150 | 12 | 28.40 |
200 x 200 | 15 | 45.30 |
MS Angle Dimensions Table (in MM)
Size (mm) | Leg A (mm) | Leg B (mm) | Thickness (mm) | Common Uses |
25 x 25 | 25 | 25 | 3–5 | Light structures, gates |
50 x 50 | 50 | 50 | 5–6 | Frames, racks |
65 x 65 | 65 | 65 | 6 | Fabrication, fencing |
75 x 75 | 75 | 75 | 6 | Industrial support beams |
100 x 100 | 100 | 100 | 6–8 | Heavy duty structures |
150 x 150 | 150 | 150 | 10–12 | Bridges, construction |
200 x 200 | 200 | 200 | 15 | Structural reinforcement |
Printable MS Angle Weight Chart (in MM & KG/Meter)
Size (mm) | Thickness (mm) | Weight (kg/m) | Leg A (mm) | Leg B (mm) |
25 x 25 | 3 | 1.10 | 25 | 25 |
25 x 25 | 5 | 1.78 | 25 | 25 |
30 x 30 | 3 | 1.34 | 30 | 30 |
30 x 30 | 5 | 2.19 | 30 | 30 |
35 x 35 | 5 | 2.60 | 35 | 35 |
40 x 40 | 5 | 3.01 | 40 | 40 |
45 x 45 | 5 | 3.43 | 45 | 45 |
50 x 50 | 5 | 3.84 | 50 | 50 |
50 x 50 | 6 | 4.56 | 50 | 50 |
60 x 60 | 6 | 5.56 | 60 | 60 |
65 x 65 | 6 | 6.08 | 65 | 65 |
70 x 70 | 6 | 6.60 | 70 | 70 |
75 x 75 | 6 | 7.12 | 75 | 75 |
80 x 80 | 6 | 7.63 | 80 | 80 |
90 x 90 | 6 | 8.65 | 90 | 90 |
100 x 100 | 6 | 9.67 | 100 | 100 |
100 x 100 | 8 | 12.70 | 100 | 100 |
110 x 110 | 10 | 17.40 | 110 | 110 |
130 x 130 | 10 | 20.64 | 130 | 130 |
150 x 150 | 10 | 23.88 | 150 | 150 |
150 x 150 | 12 | 28.40 | 150 | 150 |
200 x 200 | 15 | 45.30 | 200 | 200 |
Why These Charts Matter
Engineers, architects, and procurement officers use MS angle charts to:
- Accurately estimate weight and cost
- Ensure the right load-bearing capacity
- Avoid overuse or underuse of steel
- Save time in project planning and execution
These charts serve as a ready reckoner for structural steel requirements and ensure that your material purchase is both cost-effective and structurally sound.
If you need custom sizes, lengths, or galvanised MS Angles, connect with verified B2B platforms like Pipex.ai – India’s growing B2B marketplace for the steel industry.
