For accurate project planning and structural calculations, engineers need precise weight specifications for ERW pipes. Verified weight information for industrial applications is provided by this extensive ERW pipes weight chart in kg, mm, and pdf. Resistance of Electricity Exact specifications are necessary for welded pipes in order to handle materials and arrange transportation. Standard dimensions with certified specifications for professional engineering requirements are covered in our comprehensive weight charts.
ERW Pipes Weight Chart Specifications in t.KG and MM
Standard ERW Pipes Weight Chart
Outer Diameter (mm) | Wall Thickness (mm) | Weight per Meter (kg) | Weight per 6m Length (kg) |
21.3 | 2.6 | 1.27 | 7.62 |
26.9 | 2.6 | 1.68 | 10.08 |
33.7 | 3.2 | 2.50 | 15.00 |
42.4 | 3.2 | 3.24 | 19.44 |
48.3 | 3.6 | 4.05 | 24.30 |
60.3 | 3.6 | 5.17 | 31.02 |
76.1 | 3.6 | 6.61 | 39.66 |
88.9 | 4.0 | 8.36 | 50.16 |
114.3 | 4.5 | 12.20 | 73.20 |
139.7 | 5.0 | 16.40 | 98.40 |
168.3 | 5.4 | 21.60 | 129.60 |
219.1 | 6.3 | 32.80 | 196.80 |
273.0 | 7.1 | 46.20 | 277.20 |
323.9 | 8.0 | 61.50 | 369.00 |
Heavy-Duty ERW Pipes Weight Specifications
Outer Diameter (mm) | Wall Thickness (mm) | Weight per Meter (kg) | Weight per 12m Length (kg) |
355.6 | 9.5 | 79.80 | 957.60 |
406.4 | 9.5 | 91.20 | 1094.40 |
457.2 | 9.5 | 102.60 | 1231.20 |
508.0 | 10.0 | 120.40 | 1444.80 |
610.0 | 12.0 | 172.80 | 2073.60 |
Technical Considerations for ERW Pipes Weight Calculations
Material Properties and Steel Grade Impact
Standard carbon steel ERW pipes utilize a material density of 7.85 kg/m³ for weight calculations. Specialized alloy grades may exhibit slight density variations that affect overall weight specifications. Engineering teams must consider these material properties when conducting structural analysis and load calculations.
Wall Thickness and Structural Performance
Wall thickness directly influences pipe weight and pressure resistance capabilities. Increased wall thickness provides enhanced structural integrity but results in higher material costs and transportation requirements. Project engineers must balance these factors during specification selection processes.
Professional Procurement Through B2B Marketplace Platforms
Industrial Sourcing Solutions
Modern B2B marketplace platforms facilitate efficient ERW pipes procurement through standardized specifications and verified supplier networks. Pipex.ai provides comprehensive supplier connectivity with integrated technical databases for engineering professionals.
Logistics and Transportation Planning
Accurate weight specifications enable precise transportation cost calculations and equipment selection for material handling operations. Project managers utilize these specifications for crane capacity determination and site logistics planning.
Quality Assurance and Compliance Standards
Manufacturing Tolerance Requirements
Industry standards typically allow ±10% variation in weight specifications from theoretical calculations. Quality control procedures must account for these tolerances during material inspection and acceptance processes.
Documentation and Certification
Suppliers provide material test certificates that verify actual weight measurements against specified values. This documentation ensures compliance with project specifications and regulatory requirements for industrial applications.
Digital Resources and Technical Documentation
ERW Pipes Weight Chart PDF References
Professional suppliers offer comprehensive ERW pipes weight chart PDF documentation that includes extended specifications, material properties, and application guidelines. These technical resources serve as essential references for engineering teams and procurement professionals.
Advanced digital platforms like Pipex.ai integrate weight calculation tools with supplier databases, enabling streamlined procurement processes and technical verification capabilities for industrial buyers.
Mobile Access and Field Applications
Contemporary engineering practices require mobile access to technical specifications for field verification and on-site reference during construction and installation activities.
Summary
This ERW pipes weight chart provides essential technical data for industrial engineering applications. Accurate weight specifications support proper structural analysis, transportation planning, and procurement decisions. Professional teams benefit from utilizing standardized specifications and certified supplier networks through established B2B marketplace platforms for optimal project execution.
