The pipe weight chart in kg mtr PDF is a valuable tool for engineers, fabricators, and procurement teams involved in piping systems, structural projects, and industrial fabrication. These charts provide accurate weight per meter based on outer diameter (OD), wall thickness (mm), and material type, commonly Mild Steel (MS), Stainless Steel (SS), or Carbon Steel. Knowing the pipe weight per meter in kilograms helps in structural load calculations, cost estimation, transport planning, and material procurement. A downloadable PDF format of the pipe weight chart makes it easy to reference on-site or in design documentation.
Standard Pipe Weight Chart (Mild Steel – Per Meter in KG)
| Nominal Bore (NB) | Outer Diameter (mm) | Thickness (mm) | Weight per Meter (kg) |
|---|---|---|---|
| 15 mm | 21.3 | 2.6 | 1.22 kg |
| 20 mm | 26.9 | 2.6 | 1.59 kg |
| 25 mm | 33.7 | 3.2 | 2.63 kg |
| 32 mm | 42.4 | 3.2 | 3.39 kg |
| 40 mm | 48.3 | 3.2 | 3.91 kg |
| 50 mm | 60.3 | 3.6 | 5.44 kg |
| 65 mm | 76.1 | 3.6 | 6.98 kg |
| 80 mm | 88.9 | 4.0 | 9.63 kg |
| 100 mm | 114.3 | 4.5 | 13.68 kg |
| 150 mm | 168.3 | 4.8 | 21.55 kg |
MS (Mild Steel) Pipe Weight Chart in KG/Mtr
Size (NB) | OD (mm) | Thickness (mm) | Weight (kg/mtr) |
15mm | 21.3 | 2.6 | 1.13 |
20mm | 26.9 | 2.6 | 1.52 |
25mm | 33.7 | 3.2 | 2.44 |
32mm | 42.4 | 3.2 | 3.12 |
40mm | 48.3 | 3.2 | 3.58 |
50mm | 60.3 | 3.6 | 5.17 |
65mm | 76.1 | 3.6 | 6.61 |
80mm | 88.9 | 4.0 | 8.63 |
100mm | 114.3 | 4.5 | 12.49 |
GI (Galvanized Iron) Pipe Weight Chart in KG/Mtr
Size (NB) | OD (mm) | Thickness (mm) | Weight (kg/mtr) |
15mm | 21.3 | 2.0 | 0.94 |
20mm | 26.9 | 2.3 | 1.35 |
25mm | 33.7 | 2.6 | 2.01 |
32mm | 42.4 | 2.6 | 2.59 |
40mm | 48.3 | 2.9 | 3.26 |
50mm | 60.3 | 3.2 | 4.52 |
65mm | 76.1 | 3.2 | 5.77 |
80mm | 88.9 | 3.6 | 7.50 |
100mm | 114.3 | 4.0 | 10.93 |
Stainless Steel Pipe Weight Chart in KG/Mtr
Size (NB) | OD (mm) | Thickness (mm) | Weight (kg/mtr) |
15mm | 21.3 | 2.0 | 1.00 |
20mm | 26.9 | 2.5 | 1.55 |
25mm | 33.4 | 2.8 | 2.40 |
32mm | 42.2 | 2.8 | 3.02 |
40mm | 48.3 | 3.0 | 3.57 |
50mm | 60.3 | 3.0 | 4.48 |
65mm | 76.1 | 3.0 | 5.70 |
80mm | 88.9 | 3.5 | 7.45 |
100mm | 114.3 | 4.0 | 10.91 |
