MS washer weight chart in kg, mm, pdf is a vital reference for fabrication, construction, and mechanical assembly where weight calculations and material planning are crucial. Mild Steel (MS) washers are used to distribute load and prevent damage to surfaces during bolting or fastening. These washers come in different sizes, thicknesses, and types such as plain (flat), spring, and punched. Knowing the weight of MS washers based on dimensions (in mm) helps in bulk estimation, transport planning, and procurement. Having the washer weight data in PDF format ensures quick accessibility for engineers and purchasing departments.
Detailed MS Washer Weight Chart
Size (mm) | Inner Dia (mm) | Outer Dia (mm) | Thickness (mm) | Weight (kg) |
M3 | 3.2 | 7.0 | 0.5 | 0.0006 |
M4 | 4.3 | 9.0 | 0.8 | 0.0014 |
M5 | 5.3 | 10.0 | 1.0 | 0.0020 |
M6 | 6.4 | 12.0 | 1.6 | 0.0042 |
M8 | 8.4 | 16.0 | 1.6 | 0.0068 |
M10 | 10.5 | 20.0 | 2.0 | 0.0125 |
M12 | 13.0 | 24.0 | 2.5 | 0.0195 |
M16 | 17.0 | 30.0 | 3.0 | 0.0335 |
M20 | 21.0 | 37.0 | 3.0 | 0.0485 |
M24 | 25.0 | 44.0 | 4.0 | 0.0785 |
M30 | 31.0 | 56.0 | 4.0 | 0.1245 |
M36 | 37.0 | 66.0 | 5.0 | 0.1895 |
M42 | 43.0 | 78.0 | 7.0 | 0.3125 |
M48 | 50.0 | 92.0 | 8.0 | 0.4565 |
M56 | 58.0 | 105.0 | 9.0 | 0.6785 |
MS Flat Washer Weight Chart (Per 1000 Pieces in KG)
| Washer Size (Bolt Size) | Outer Dia (mm) | Thickness (mm) | Weight/1000 pcs (kg) |
|---|---|---|---|
| M6 | 12 | 1.6 | 2.00 kg |
| M8 | 16 | 1.6 | 3.50 kg |
| M10 | 20 | 2.0 | 6.50 kg |
| M12 | 24 | 2.5 | 10.00 kg |
| M16 | 30 | 3.0 | 18.00 kg |
| M20 | 37 | 3.0 | 28.00 kg |
