This blog offers a comprehensive look at Stud Bolts Weight Chart in kg, dimensions in mm, and provides access to PDF charts for quick reference. We’ll also highlight how sourcing through B2B platforms like Pipex.ai can streamline the procurement process for buyers and engineers alike.
Stud Bolts Weight Chart mm and kg
Below is a sample Stud Bolts Weight Chart mm and its corresponding weight in kg per 100 pieces. This chart helps engineers and buyers understand how much weight a certain quantity of stud bolts will add to a structure or shipment.
Bolt Size (mm) | Length (mm) | Weight (kg/100 pcs) |
M6 | 50 | 2.00 |
M6 | 100 | 3.50 |
M8 | 50 | 3.00 |
M8 | 100 | 5.20 |
M10 | 75 | 5.80 |
M10 | 100 | 7.50 |
M10 | 150 | 10.50 |
M12 | 100 | 11.20 |
M12 | 150 | 14.80 |
M12 | 200 | 18.50 |
M16 | 100 | 13.80 |
M16 | 150 | 19.80 |
M16 | 200 | 25.50 |
M20 | 100 | 22.50 |
M20 | 150 | 28.50 |
M20 | 200 | 32.00 |
M20 | 250 | 39.00 |
M24 | 100 | 30.00 |
M24 | 150 | 38.50 |
M24 | 200 | 46.50 |
M24 | 250 | 55.00 |
M30 | 100 | 50.00 |
M30 | 150 | 63.00 |
M30 | 200 | 75.00 |
M30 | 250 | 87.00 |
M36 | 150 | 90.00 |
M36 | 200 | 110.00 |
M36 | 300 | 145.00 |
M42 | 150 | 115.00 |
M42 | 200 | 140.00 |
M42 | 300 | 185.00 |
M48 | 200 | 185.00 |
M48 | 250 | 220.00 |
M48 | 300 | 260.00 |
