The Threaded Flanges Manufacturer is the producer of threaded flange parts of different sizes, materials and pressure to support the needs of industrial, oil and gas, and the piping industry. The Threaded Flanges Weight Chart in KG, MM, PDF is a basic tool that engineers, contractors and procurement individuals can use when planning projects and buying materials and estimating loads. Threaded flanges Threaded flanges, such as Stainless Steel Threaded Flanges and Threaded Screwed Flanges, are commonly used to join pipes without welding, so they are applicable in low-pressure applications, tight space assembly and systems that need to be disassembled.
The Threaded Flanges Weight Chart offers the specifications of the flange sizes, thread type, and weight per unit of various sizes and pressure classes. The threaded flanges are classified according to standards (ANSI, ASME, DIN, IS) and materials such as carbon steel, alloy steel and stainless steel. Their flanges are very resistant to corrosion, durable and have a long life, hence they are suitable in pipelines, chemical plants, water systems and industrial installations.
Threaded Flanges Weight Chart, Threaded Flanges Per Piece, Threaded Flanges Weight Chart in KG, Threaded Flanges Weight Chart in MM, Threaded Flanges Weight Calculator, Threaded Flanges Specifications PDF
Weight Chart Tables
Chart 1: Threaded Flanges Weight Chart – Standard Pressure
Nominal Size (mm) | Diameter (mm) | Thread Type | Weight per Piece (kg) | Weight per 10 Pieces (kg) |
15 | 95 | NPT | 0.30 | 3.0 |
25 | 105 | NPT | 0.50 | 5.0 |
40 | 115 | NPT | 0.85 | 8.5 |
50 | 125 | NPT | 1.10 | 11.0 |
80 | 150 | NPT | 2.20 | 22.0 |
100 | 180 | NPT | 3.50 | 35.0 |
Small diameter pipes that are connected to low-pressure systems are normally attached using threaded flanges, which are easy to install and maintain.
Chart 2: Threaded Flanges Material Grades & Standards
Material Grade | Standard | Composition Type | Tensile Strength (MPa) | Application |
ASTM A105 | ASTM / ASME | Carbon Steel | 485 | Low-pressure pipelines |
ASTM A182 F304 | ASTM | Stainless Steel | 515 | Chemical & food processing |
ASTM A182 F316 | ASTM | Stainless Steel | 515 | Corrosive fluid systems |
ASTM A350 LF2 | ASTM | Carbon Steel | 250 | Low-temp applications |
DIN 2633 | DIN | Carbon Steel | 420 | General industrial piping |
The material grades also guarantee adherence to the international standards and allow them to be used in various pressures, temperatures, and fluid types.
Chart 3: Threaded Flanges Dimensions & Weight Chart
Nominal Size (mm) | Diameter (mm) | Thickness (mm) | Weight per Piece (kg) |
15 | 95 | 10 | 0.30 |
25 | 105 | 12 | 0.50 |
40 | 115 | 14 | 0.85 |
50 | 125 | 16 | 1.10 |
80 | 150 | 18 | 2.20 |
100 | 180 | 20 | 3.50 |
Threaded flanges can be assembled and disassembled easily without welding and this contributes to a low cost of labor and minimal maintenance downtime. These Threaded Flanges weight charts in KG and MM are useful in estimating materials, calculating cost and planning of the project in industries, commercial and construction projects.
