Hastelloy B3 Plates Manufacturer In India Supplying Astm B333 / Asme Sb333 Standard Plates For Chemical Processing

Name: Hastelloy B3 Plates Manufacturer In India Supplying Astm B333 / Asme Sb333 Standard Plates For Chemical Processing
Brand: United Stainless Llp
Availability: InStock
Rating: 4 (16 reviews)

Specification Details
Plate Standards	Astm A240, / Asme Sa240
Material Grades	405, 436l, 409, 441, 446, 409l, 410, 430ti, 409m, 410s, 410db, 415, 416, 420, 430, 431, 439, 436
Surface	Embossed, 2b, 2d, Ba, Hair Line, No.1, No.4, Sand Blast, No.8, Brush, 8k, Etching, Mirror, Checkered, Etc
Finish	Hot Rolled Plate (hr), Satin (met With Plastic Coated), Cold Rolled Plate (cr), 2b, 2d, Ba No(8)

Hastelloy B3 Plates Manufacturer in India Delivering Export-Quality Plates Conforming to ASTM, ASME & EN Standards

United Stainless LLP is the major Hastelloy B3 Plate Manufacturer in India and it provides high performance nickel-molybdenum alloy plates which are manufactured to provide high thermal stability and severe reducing environment resistance. The Hastelloy B3 Plates find a lot of application in the chemical processing equipment, reactors, and heat exchangers where the uniform corrosion resistance and mechanical reliability are necessary.

Hastelloy B3 Plates are procured via a stable B2B marketplace and delivered in various thicknesses and surface finishes that would cater to varying needs of industries. These plates are included in a complete spectrum of Hastelloy Plates, and complementary grades like Hastelloy B2 Plates and Hastelloy C22 Plates are chosen to be used when different profiles of corrosion, and temperatures are involved.

Hastelloy B3 Plates possess good resistance to hydrochloric and sulfuric acids, acceptable fabricability and weldability. Being a reliable Hastelloy B3 Plate Supplier In India, goods are produced based on the international standards and are tested to be of long life, strength and performance in the aggressive service conditions.

Material & Grades of Hastelloy B3 Plates

The Hastelloy B3 Plates come in standardized grades to be used in the demanding industrial applications.

Material	Grade / Standard	UNS No.	Thickness (mm)	Width (mm)	Typical Applications
Hastelloy	B3	N10675	2.0 – 50.0	1000 – 2000	Chemical reactors
Hastelloy	B2	N10665	2.0 – 50.0	1000 – 2000	Heat exchangers
Hastelloy	C22	N06022	1.0 – 50.0	1000 – 2000	Pollution control
Hastelloy	C276	N10276	2.0 – 60.0	1000 – 2000	Process equipment

Key Features & Advantages

Enhanced thermal stability
Excellent resistance to reducing acids
Good weldability and formability
High mechanical strength
Long service life
Custom sizes available

Hastelloy B3 Plates Equivalent Grades :

STANDARD WERKSTOFF NR. UNS
Hastelloy B3 2.4600 N10675

Chemical Composition of Hastelloy Alloy B3 Plate

Grade	C	Mn	Si	Al	Co	Ni	Cr	Fe	Mo	Ti
Hastelloy B3	0.01 max	3.0 max	0.10 max	0.50 max	3.0 max	65.0 min	1.5	1.5	28.5	0.2 max

Mechanical Properties of Hastelloy B3 Plates

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
9.22 g/cm3	1418°C (2585°F)	1000 – 2000 N/mm² , 145 - 290 ksi	62 - 183 Ksi, 425 – 1260 MPa	57 %
