Advanced Inconel Wire Mesh Manufacturer & Supplier | Nickel Alloy Grade | Bhansali Wire Mesh
| Standard | Astm A580, A493 / Asme Sa580 |
|---|---|
| Length | 0.125", 72 |
| Diameter | 10 Microns 1.0 Mm |
| Technique | Cold Rolled, Hot Rolled |
Inconel Wire Mesh manufacturer in india
Bhansali Wire Mesh is a well-known Inconel Wire Mesh Manufacturer which provides high-quality wire mesh that is suited to work in an extreme industrial setting. These meshes are made using high-grade Inconel alloys that are highly resistant to oxidation, heat, and corrosion, hence suitable for use in chemical plants and the aerospace and marine industries. The weaving of every mesh is done with precision to guarantee that it has dimensional accuracy, strength, and longevity of performance in high-stress conditions as per international standards of quality.
Inconel wire mesh products that are durable are easily sourced by industries through a reliable B2B platform that guarantees efficiency and reliability of these products in an operation that has challenging demands. Among the sub-products, Stainless Steel Wire Mesh is one of the most popular, acclaimed for its excellent tensile strength and pitting and crevice resistance to corrosion. The use of this mesh is very ideal in filtration systems, heat exchangers, and other parts of turbines where durability and performance are very important factors when it comes to the success of industries.
Inconel Wire Mesh Weight Chart
| Mesh Size (Aperture/Mesh Count) | Wire Diameter (mm) | Mesh Width (mm) | Weight per Meter (kg/m) | Total Weight (kg) – 10 m Roll |
|---|---|---|---|---|
| 10 Mesh | 0.50 | 1000 | 4.20 | 42.00 |
| 20 Mesh | 0.40 | 1000 | 5.60 | 56.00 |
| 40 Mesh | 0.30 | 1000 | 7.90 | 79.00 |
| 60 Mesh | 0.25 | 1000 | 9.80 | 98.00 |
| 80 Mesh | 0.20 | 1000 | 11.50 | 115.00 |
Inconel wire mesh is able to be used in the aerospace, chemical processing, and heat treatment industries because it is designed to be used in extreme temperature environments and high levels of corrosion. It is structurally sound to extreme thermal and mechanical loads. The weight chart will be required in assessing the load capacity, thermal expansion, and feasibility of installation. Proper weight data improves proper mesh selection, handling, and effective operation of important industrial systems.
Key Features & Advantages
- Excellent resistance to high-temperature oxidation
- Strong corrosion resistance in demanding chemical environments
- Good mechanical strength at elevated temperatures
- High resistance to pitting and crevice corrosion in suitable grades
- Suitable for furnace and heat-treatment applications
- Available in fine and coarse filtration configurations
- Customizable mesh count, wire diameter, weave, and dimensions
Chemical Composition
Representative Grade: Inconel 625
| Element | Percentage (%) |
| Nickel (Ni) | 58.0 min. |
| Chromium (Cr) | 20.0–23.0 |
| Molybdenum (Mo) | 8.0–10.0 |
| Niobium + Tantalum (Nb + Ta) | 3.15–4.15 |
| Iron (Fe) | 5.0 max. |
| Carbon (C) | 0.10 max. |
Mechanical Properties
| Property | Value |
| Tensile Strength | 827 MPa min. |
| Yield Strength | 414 MPa min. |
| Elongation | 30% min. |
| Hardness | Approx. 145–220 HB |
Equivalent Grade
| Standard | Grade |
| ASTM | B443 / B446 – 625 |
| UNS | N06625 |
| EN | 2.4856 |
| DIN | NiCr22Mo9Nb |
Type of Sub-products
Frequently Asked Questions
Which material should I choose for Inconel Wire Mesh?
Which specifications are available for Inconel Wire Mesh?
How can I select suitable Inconel Wire Mesh?
Does Bhansali Wire Mesh provide custom manufacturing?
Which locations are served by Bhansali Wire Mesh?
How can I get a quotation?
Countries We Export
India
Cities We Supply
Lucknow
Mumbai
Nashik
Pune
Rajkot
Moradabad
Angul
Rudrapur
Hosdurg
Gandhinagar
Rajahmundry
Durgapur
Bharuch
Panipat
Industries We Serve
Sugar
Oil And Gas Industries
Paper Mill
Power Plant
Bridge And Building
Aerospace Industries
Automobile Industry
Electrical Industry
Defense Industry
Construction & Fabrications
Ring Man Units
Railways
Pharmaceuticals Industry
