Monel 400 Sheet Manufacturer In India Delivering Export Quality Sheets Conforming To Astm, Asme & En Standards
| Size range | 1000 Mm X 2000mm, 1500mm X 3000mm To 6000mm, 1220mm X 2440mm, 2000mm X 4000mm To 6000mm, 4' X 8', 1250mm X 2500mm |
|---|---|
| Range | 5mm, 150mm |
| Thickness | 4.0mm, 100mm |
| Specialize | Perforated Sheet, B. Q. Profile, Shim Sheet |
Monel 400 Sheet Manufacturer in India Supplying ASTM B165 / ASME SB165 Standard Sheets for Chemical & Marine Industries
United Stainless LLP is a major Monel 400 Sheet Manufacturer In India, which manufactures nickel-copper alloy sheets which are known to have excellent resistance to seawater, hydrofluoric acid, and other highly corrosive conditions. Monel 400 Sheet, is mainly utilized in the marine engineering, chemical processing, desalination plants and heat exchangers that demand high corrosion resistance and high strength.
These sheets are available in various thicknesses and surface finishes through a reliable B2B portal and to suit high standards of the industrial demand. It also has Monel Sheets that can be used in general corrosion-resistant and Monel K500 Sheet used in high-strength applications that demand extra hardness.
The monel 400 sheet is very susceptible to pitting, crevice corrosion and stress corrosion cracking, that is why it is preferred in seawater equipment, chemical vessel as well as offshore. These sheets are very durable and performance guaranteeing in harsh environments, as they are a trusted Monel 400 Sheet Supplier In India. We offer Incoloy Sheets ideal for chemical processing, heat exchangers, power generation, and marine applications.
Material & Grades of Monel 400 Sheet
Monel 400 Sheet is produced under strict quality standards to ensure uniform composition, mechanical strength, and corrosion resistance for demanding industrial applications.
| Material | Grade / Standard | UNS No. | Thickness (mm) | Width (mm) | Typical Applications |
|---|---|---|---|---|---|
| Monel Alloy | 400 | N04400 | 0.5 – 50.0 | 1000 – 2000 | Marine & seawater equipment |
| Monel Alloy | K500 | N05500 | 0.5 – 40.0 | 1000 – 2000 | High-strength applications |
| Monel Alloy | 405 | N04405 | 0.8 – 30.0 | 1000 – 1500 | Chemical processing |
| Monel Alloy | 450 | N04450 | 1.0 – 25.0 | 1000 – 1500 | Offshore & marine structures |
Key Features & Advantages
- Excellent resistance to seawater and acidic environments
- High strength and hardness for critical applications
- Outstanding resistance to stress corrosion cracking
- Good weldability and formability
- Long-term durability in marine and chemical industries
- Supplied in standard and custom sizes
Monel 400 Sheet Chemical Composition
Monel 400 Sheets are corrosion resistant due to the presence of carbon, silicon, sulfur, and other elements.
| Grade | Ni | Fe | C | Mn | Si | Cu | Al | S |
|---|---|---|---|---|---|---|---|---|
| Monel 400 | 63.0 min | 1.0 – 2.5 | 0.3 max | 2.0 max | 0.5 max | 28.0 – 34.0 | 0.50 max | 0.02 max |
Monel 400 Sheet Mechanical Properties
Mechanical Properties of Monel 400 Sheets are listed below to assist you understand the product's durability.
| Grade | Density | Melting Point | Tensile Strength Psi, Mpa | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | 80,000, 550 | 240 Mpa | 40 % |
Monel 400 Sheet Equivalent Grade
Our dedication to quality guarantees that every Monel Sheet meet the highest standards, establishing us as a reliable Monel 400 Sheet Manufacturer in India.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| Monel 400 | 2.4360 | N04400 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
Monel 400 Sheet Size Chart
Monel 400 Sheets may be customized in any thickness to meet the needs of the client; the table below shows the standard thickness of Monel 400 Sheet.
| Width (mm) | Length (mm) |
|---|---|
| 914 & 1219 | 1828 & 2438 |
| 914, 1219 & 1500 | 1828, 2438, 3000, 3048 & 3658 |
| 1500 & 2000 | 3000 & 6000 |
| 1219 | 2438 |
| 1219 & 1500 | 2438, 3000 & 3658 |
| 1500 & 2000 | 3000 & 6000 |
| 914 & 1219 | 1828 & 2438 |
| 1250 | 2500 |
| 1250 & 1500 | 2500, 3000 & 6000 |
| 1250 & 1500 | 2500, 3000 & 6000 |
Type of Sub-products
Frequently Asked Questions
Where are Monel 400 sheets commonly used?
Can Monel 400 sheets be customized in terms of size and thickness?
