| Specifications | Astm, Asme, Din, Nfa, Jis |
|---|---|
| Thickness | 4.0mm, 100mm |
| Pipes Size | 1/8” Nb, 24” Nb, 1/4” Od, 24” Od Sizes |
| Tubes Size | 1/2″ Od, 8″ Od |
| Length: | Cut Length, Fix Length, Single Random, Double Random, Required Length |
| End | Plain End, Beveled End, Threaded |
Pipes and Tubes, High Quality Material | SS 304/304L, 316/316L, 321, Duplex 2205, ASTM A213, A312, Industrial Seamless Pipes
Neptune Metal Industries stands as a reliable name in the global pipes and tubes manufacturer segment, delivering high-performance solutions tailored to meet the evolving needs of industries such as oil & gas, petrochemicals, power plants, construction, and marine engineering. In the current B2B marketplace, which is a fast-paced market, customers are not merely seeking goods, but customers are seeking consistency in quality and compliance with international standards as well as long-term functionality. The quality of pipes and tubes is very important, and their material composition is essential in fluid transportation, structural support and pressure-handling applications. These products are produced with accuracy in their dimensional, smooth surface finish and high mechanical properties since they are produced in seamless, welded forms. The growing need for corrosion-resistant and high-strength materials has also enhanced the popularity of the stainless steel pipes and tubes among the industries that operate under extreme conditions and high temperatures.
The company, being a major stainless steel seamless pipe supplier, is focused on providing a complete grade of seamless pipes which meets the application needs of different customers. Popular grades include SS 304 and SS 304L, which offer excellent resistance to corrosion and cost-effectiveness, whilst SS 316 and SS 316L offer higher resistance to chlorides and acidic conditions which are typical in marine and chemical processing industries. In high-temperature applications, SS 321 is more stable because of the titanium content, and Duplex 2205 is more efficient with the advantages of both high strength and high corrosiveness, and thus is applicable under conditions of high demands. Such grades make pipes and tubes structurally sound, scale-resistant, and efficient even in severe pressure and temperature situations. Selecting an appropriate grade of material does not only enhance the efficiency of the operations but also lowers the maintenance expenses and increases the duration of the whole system, which is a very significant consideration in the purchase of the material for the buyers in the industrial procurement process.
Pipes and Tubes Dimensions Chart
| NPS | Outside Diameter | Nominal Wall Thickness | ||||||||
| Designator | in. | mm | Schedule 5S | Schedule 10S | Schedule 40S | Schedule 80S | ||||
| in. | mm | in. | mm | in. | mm | in. | mm | |||
| 1/8 | 0.41 | 10.29 | … | … | 0.049 | 1.24 | 0.068 | 1.73 | 0.095 | 2.41 |
| 1/4 | 0.54 | 13.72 | … | … | 0.065 | 1.65 | 0.088 | 2.24 | 0.119 | 3.02 |
| 3/8 | 0.68 | 17.15 | … | … | 0.065 | 1.65 | 0.091 | 2.31 | 0.126 | 3.2 |
| 1/2 | 0.84 | 21.34 | 0.065 | 1.65 | 0.083 | 2.11 | 0.109 | 2.77 | 0.147 | 3.73 |
| 3/4 | 4.05 | 26.67 | 0.065 | 1.65 | 0.083 | 2.11 | 0.113 | 2.87 | 0.154 | 3.91 |
| 1 | 1.32 | 33.4 | 0.065 | 1.65 | 0.109 | 2.77 | 0.133 | 3.38 | 0.179 | 4.55 |
| 1 1/4 | 1.66 | 42.16 | 0.065 | 1.65 | 0.109 | 2.77 | 0.14 | 3.56 | 0.191 | 4.85 |
| 1 1/2 | 1.90 | 48.26 | 0.065 | 1.65 | 0.109 | 2.77 | 0.145 | 3.68 | 0.2 | 5.08 |
| 2 | 2.38 | 60.33 | 0.065 | 1.65 | 0.109 | 2.77 | 0.154 | 3.91 | 0.218 | 5.54 |
| 2 1/2 | 2.88 | 73.03 | 0.083 | 2.11 | 0.12 | 3.05 | 0.203 | 5.16 | 0.276 | 7.01 |
| 3 | 3.50 | 88.9 | 0.083 | 2.11 | 0.12 | 3.05 | 0.1216 | 5.49 | 0.3 | 7.62 |
| 3 1/2 | 4.00 | 101.6 | 0.083 | 2.11 | 0.12 | 3.05 | 0.226 | 5.74 | 0.318 | 8.08 |
| 4 | 4.50 | 114.3 | 0.083 | 2.11 | 0.12 | 3.05 | 0.237 | 6.02 | 0.337 | 8.56 |
| 5 | 5.56 | 141.3 | 0.10*9 | 2.77 | 0.134 | 3.4 | 0.258 | 6.55 | 0.375 | 9.52 |
| 6 | 6.63 | 168.28 | 0.10*9 | 2.77 | 0.134 | 3.4 | 0.28 | 7.11 | 0.432 | 10.97 |
| 8 | 8.63 | 219.08 | 0.109 | 2.77 | 0.148 | 3.76 | 0.322 | 8.18 | 0.5 | 12.7 |
| 10 | 10.75 | 273.05 | 0.134 | 3.4 | 0.165 | 4.19 | 0.365 | 9.27 | 0.5 | 12.7 |
| 12 | 12.75 | 323.85 | 0.156 | 3.96 | 0.18 | 4.57 | 0.375 | 9.52 | 0.5 | 12.7 |
| 14 | 14.00 | 355.6 | 0.156 | 3.96 | 0.188 | 4.78 | … | … | … | … |
| 16 | 16.00 | 406.4 | 0.165 | 4.19 | 0.188 | 4.78 | … | … | … | … |
| 18 | 18.00 | 457.2 | 0.165 | 4.19 | 0.188 | 4.78 | … | … | … | … |
| 20 | 20.00 | 508 | 0.188 | 4.78 | 0.188 | 4.78 | … | … | … | … |
| 22 | 22.00 | 558.8 | 0.188 | 4.78 | 0.218 | 5.54 | … | … | … | … |
| 24 | 24.00 | 609.6 | 0.218 | 5.54 | 0.25 | 6.35 | … | … | … | … |
| 30 | 30.00 | 762 | 0.25 | 6.35 | 0.312 | 7.92 | … | … | … | … |
Type of Sub-products
Frequently Asked Questions
What materials are pipes and tubes available in?
Can pipes and tubes be supplied in bulk quantities?
