PIPE FITTINGS

View By:

₹82 - ₹173

Min. order: 50 piece

Pipe Fittings Manufacturer In India – Astm A420 Wpl6 Low Temperature Pipe Fittings

Minox Inc

Verified 1.0

2 yrs

Specifications: Astm, Asme, Din, Nf, Jis, En, IosSize Range: 1/2"nb To 48"nb, 1/2"nb, 48"nbDimension: Asme/ansi B16.9, Asme B16.28, Mss Sp 43

Compression_tube_fittings_manufacturer_in_india

₹45 - ₹136

Min. order: 100 piece

Compression Tube Fittings Manufacturer In India – Astm A182 F316 High Pressure Tube Fittings

Minox Inc

Verified 1.0

2 yrs

Material: Brass, Carbon Steel, Alloy Steel, Plastic Pvc/ PtfeThread Type: Npt, Bsp, Bspt, Iso, MetricConnection Type: Compression, Push To Connect, Welded, Threaded, Flared, Barbed

₹5,002 - ₹22,73,750

Min. order: 1 Pieces

MILD STEEL / CARBON STEEL FLANGES

Verified 1.0

2 yrs

Specifications: Astm, Din, Asme, Jis, En, Ios, NfSize Range: 1/2"nb To 48"nbDimension: Asme/ansi B16.9, Asme B16.28, Mss Sp 43

If you don't have a product, please fill out the RFQ form

Pipe Fittings are essential parts in a piping system applied in industrial, construction, engineering and fabrication to join, redirect, control and change direction or size of piping systems. They come in a variety of materials, grades, size, wall thickness and specification as per the requirement of the piping. Commonly found types are elbows, tees, reducers, couplings, crosses, caps and bends in stainless steel, carbon steel, alloy steel and other metal materials. Pipe Fittings are used on a broad range of applications, including oil and gas, chemical processing, petrochemical, power generation, water treatment, construction and general industrial uses. Choosing an appropriate material grade, size, pressure rating and relevant standard guarantees stable connections, good flow and stable piping system performance over a long period of time.

Pipe Fitting Chemical Composition Chart PDF:

Pipe Fittings Chemical Composition Table, Pipe Fitting Chemical Chart, Steel Pipe Fittings Chemical Composition Chart

CHEMICAL COMPOSITION (IN PERCENTAGE )
Grade	C (Max)	Mn (Max)	P(Max)	S (Max)	Si (Max)	Cr	Ni	Mo	Nitrogen (Max)	Cu/ Others
301	0.15	2.00	0.045	0.030	1.00	16.00 - 18.00	6.00 - 8.00	-	0.10	-
304	0.08	2.00	0.045	0.030	0.75	18.00 - 20.00	8.00- 10.50	-	0.10	-
304L	0.030	2.00	0.045	0.030	0.75	18.00 - 20.00	8.00- 12.00	-	0.10	-
310S	0.08	2.00	0.045	0.030	1.50	24.00- 26.00	19.00 - 22.00	-	-	-
316	0.08	2.00	0.045	0.030	0.75	16.00 - 18.00	10.00 - 14.00	2.00 - 3.00	0.10	-
316L	0.030	2.00	0.045	0.030	0.75	16.00 - 18.00	10.00 - 14.00	2.00 - 3.00	0.10	-
317	0.08	2.00	0.045	0.030	0.75	18.00 - 20.00	11.00 - 14.00	3.00 - 4.00	0.10	-
317L	0.030	2.00	0.045	0.030	0.75	18.00 - 20.00	11.00 - 15.00	3.00 - 4.00	0.10	-
321	0.08	2.00	0.045	0.030	0.75	17.00 - 19.00	9.00 - 12.00	-	0.10	Ti5 ( C + N ) Min or 0.70 max
347	0.08	2.00	0.045	0.030	0.75	17.00 - 19.00	9.00 - 13.00	-	-	Cb= 10x ( C Min ) or 1.00 Max
409	0.08	1.00	0.040	0.010	1.00	10.50 - 11.75	0.50	-	-	Ti= 6x (C+ N ) Min or 0.70 Max
409M	0.03	0.81.2	0.030	0.030	0.40.75	11.00- 12.00	1.5 max.	-	-	Ti= 6x (C) Min or 0.70 Max
410S	0.08	1.00	0.040	0.030	1.00	11.50- 13.50	0.60	-	-	-
410	0.15	1.00	0.040	0.030	1.00	11.50- 13.50	0.75	-	-	-
420	0.35	0.50	0.035	0.015	0.50	12.00 - 13.00	0.20.3	-	-	-
430	0.12	1.00	0.040	0.030	1.00	16.00 - 18.00	0.75	-	-	-
JSL AUS	0.08	7.08.0	0.070	0.030	0.75	15.50 - 16.50	4.25 - 4.75	-	-	0.9 - 1.10
JS- 203	0.08	9.2510.25	0.070	0.030	0.75	14.25 - 15.25	2.25 - 2.75	-	-	1.60- 2.0
301M	0.10	4.55.5	0.060	0.030	0.75	14.50 - 15.50	6.0 - 7.0	-	-	1.70- 1.90

This chemical composition chart highlights the precise alloying elements that define each stainless steel grade, from austenitic types like 304, 316, and 310S to stabilized grades such as 321 and 347, and ferritic options like 409 and 430. Each grade features controlled levels of carbon, chromium, nickel, and other elements to deliver specific properties such as corrosion resistance, heat stability, and strength. Special variants like JSL AUS, JS-203, and 301M offer enhanced performance through optimized manganese, nitrogen, and copper content. This table serves as a quick reference for engineers and manufacturers to select the right grade based on required chemical balance and application needs.
