| Size | 20*20 |
|---|---|
| Type | Bolt, Nut, Screw, Washer, Rivet, Threaded Rod, Studs, Coated, Nails, Custom Fasteners |
| Standard | Din, Iso, Jis, Gb, Is, Bs, Astm |
| Length | 100mm |
| Material | Stainless Steel, Monel, Inconel, Incoloy, Hastelloy, Nickel, Silicon Bronze, Phosphor Bronze |
Countersunk Bolts India | High Quality Grade 8.8, 10.9, 12.9, Stainless Steel Fasteners
Delta Fitt Inc. is a major Countersunk Bolts Manufacturer that provides high quality fastening solutions which are used in those applications where a smooth, flush finish of the surface is necessary. These bolts are designed in an accurate manner so that they fit in tightly and in place, hence suitable in machinery, automotive assembly, structural frameworks and equipment fabrication. They are made of the highest quality materials including stainless steel, alloy steel and carbon steel that provide exceptional strength, durability and corrosion resistance. These countersunk bolts can be found in different sizes, styles, and specifications so that the resultant installation can be optimized in terms of performance, and add to the overall looks and functionality.
Countersunk Bolts are necessary in the B2B industry because of the protruding head that produces a seamless joint, a feature that is very important in terms of safety and design efficiency. They are widely applied in industries such as construction, engineering, furniture production, and metalworking, where accuracy and dependability are very important. These Bolts have high torque, high holding capacity, and durability, and therefore they have been a favorite among the companies that are interested in finding reliable fastening products. They can be applied in a large variety of commercial and industrial applications due to their versatility and performance.
Countersunk Bolt Chemical Composition
| Material | Chemical Composition |
|---|---|
| Stainless Steel | Chromium (16-18%), Nickel (10-14%), Manganese (2%), Silicon (1%), Carbon (0.08%), Phosphorus (0.045%), Sulfur (0.03%) |
| Carbon Steel | Carbon (0.12-2%), Manganese (0.6-2%), Phosphorus (0.045%), Sulfur (0.05%), Silicon (0.05%) |
| Titanium | Titanium (99%), Aluminum (6%), Vanadium (4%), Iron (0.25%), Oxygen (0.2%) |
Countersunk Bolt Mechanical Properties
The Mechanical Properties of Countersunk Bolt are highly valued in various industries, such as chemical, oil and gas, pulp, and paper. These properties include strength, and toughness which make Countersunk Bolt highly resistant to corrosion and other types of damage.
| Material | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation at Break (%) |
|---|---|---|---|
| Stainless Steel | 500-700 | 200-450 | 50-60 |
| Carbon Steel | 400-550 | 250-420 | 25-30 |
| Titanium | 880-1100 | 780-900 | 15-25 |
Countersunk Bolt Dimensions
There are several types you need to consider when choosing the Dimensions of Countersunk Bolt
| Bolt Diameter | D | F | H | |||
|---|---|---|---|---|---|---|
| Body Diameter | Head Diameter | Head Height | ||||
| Max | Max Edge Sharp | Min Edge Sharp | Absolute Min Rounded | Max | Min | |
| 1⁄2 | 0.515 | 0.935 | 0.905 | 0.845 | 0.269 | 0.233 |
| 5⁄8 | 0.642 | 1.169 | 1.132 | 1.066 | 0.336 | 0.292 |
| 3⁄4 | 0.768 | 1.402 | 1.357 | 1.285 | 0.403 | 0.349 |
| 7⁄8 | 0.895 | 1.637 | 1.584 | 1.511 | 0.470 | 0.408 |
| 1 | 1.022 | 1.869 | 1.810 | 1.735 | 0.537 | 0.466 |
| 11⁄8 | 1.149 | 2.104 | 2.037 | 1.962 | 0.604 | 0.525 |
| 11⁄4 | 1.277 | 2.337 | 2.262 | 2.187 | 0.671 | 0.582 |
| 13⁄8 | 1.404 | 2.571 | 2.489 | 2.414 | 0.738 | 0.641 |
| 11⁄2 | 1.531 | 2.804 | 2.715 | 2.640 | 0.805 | 0.698 |
Client Projects For Countersunk Bolt
Product Supplied | Quantity | Location (India) |
Countersunk Bolt Supplied To Oil & Gas Industry | 250 Pieces | Mumbai |
Countersunk Bolt Supplier | 210 Pieces | Hyderabad |
Countersunk Bolt Manufacturer | 100 Pieces | Chennai |
Countersunk Bolt Supplier | 180 Pieces | Pune |
Type of Sub-products
Frequently Asked Questions
Which standards do Countersunk Bolts conform to?
What is a Countersunk bolt?
