Spring Lock Washer Manufacturer | Astm F436 High Strength Lock Washers

Name: Spring Lock Washer Manufacturer | Astm F436 High Strength Lock Washers
Brand: Apex Pipe & Fabrication
Availability: InStock
Rating: 5 (4 reviews)

Specification Details
Size	M4 to M60
Type	Washer
Standard	Din, Iso, Jis, Gb, Is, Bs, Astm
Length	3000 mm
Material	Stainless Steel, Monel, Inconel, Incoloy, Hastelloy, Nickel, Silicon Bronze, Phosphor Bronze

Spring Lock Washer Manufacturer | Precision Engineered Lock Washers DIN 127

Apex Pipe and Fabrication is well known as a reliable Spring Lock Washers Manufacturer, and it provides durable and precision-made products that are used in industries. Spring Lock Washers are specially designed fastening elements that are applied in order to avoid loosening due to vibration and dynamic loads in mechanical assemblies. The tension is offered by these washers by applying a spring force between the fastener head and the surface, creating a secure and stable joint. In simple terms, in fastening systems, Wedge Lock Washers are also being employed in an advanced solution whereby greater vibration resistance is needed.

The spring lock washers are produced according to the standards of DIN, ASTM, and ISO with high-quality materials, which guarantee their strength and durability. They are common in the automotive industry, construction industry, and machinery industry to preserve tight connections during stress situations. Industries that need bulk fastening solutions usually get these washers sourced by a trusted b2b marketplace. Their easy to install, simple design and locking system are necessitated by the fact that they are needed in applications where safety and performance are paramount.

Material & Grades Table – Spring Lock Washers

Material Grade / Standard Size / Thickness / Diameter Extra Specification Weight (kg/1000 pcs)
Stainless Steel SS 304 / ASTM F593 M3–M36 General-purpose corrosion-resistant lock washer Approx. 1–250
Stainless Steel SS 316 / ASTM F593 M3–M36 Marine and chemical applications Approx. 1–250
Stainless Steel SS 316L M3–M36 Low-carbon corrosion-resistant construction Approx. 1–250
Carbon Steel SAE 1070–1090 M3–M48 Spring-grade carbon steel Approx. 1–400
Carbon Steel ASTM F844 M3–M48 General-purpose washer applications Approx. 1–400
Alloy Steel 65Mn / Spring Steel M4–M48 High-strength spring washer applications Approx. 1–450
Alloy Steel 50CrV4 M4–M48 High-performance spring steel Approx. 1–450
Brass C26000 M3–M24 Electrical and specialized applications Approx. 1–180

Material	Grade / Standard	Size / Thickness / Diameter	Extra Specification	Weight (kg/1000 pcs)
Stainless Steel	SS 304 / ASTM F593	M3–M36	General-purpose corrosion-resistant lock washer	Approx. 1–250
Stainless Steel	SS 316 / ASTM F593	M3–M36	Marine and chemical applications	Approx. 1–250
Stainless Steel	SS 316L	M3–M36	Low-carbon corrosion-resistant construction	Approx. 1–250
Carbon Steel	SAE 1070–1090	M3–M48	Spring-grade carbon steel	Approx. 1–400
Carbon Steel	ASTM F844	M3–M48	General-purpose washer applications	Approx. 1–400
Alloy Steel	65Mn / Spring Steel	M4–M48	High-strength spring washer applications	Approx. 1–450
Alloy Steel	50CrV4	M4–M48	High-performance spring steel	Approx. 1–450
Brass	C26000	M3–M24	Electrical and specialized applications	Approx. 1–180

The table above gives a summary of the most popular materials and grades of Spring Lock Washers and their dimensional range. These specifications are used in choosing the correct washer depending on the application specifications, including load volume, resistance to corrosion, and environmental factors in the different industrial applications.
