Stainless Steel Cross Fitting Manufacturers , Suppliers & Exporters | Astm A403, Asme Sa403 Grades | Western Steel Agency
| Specifications | Astm, Asme, Din, Nf, Jis, En, Ios |
|---|---|
| Size Range | 1/2"nb To 48"nb, 1/2"nb, 48"nb |
| Dimension | Asme/ansi B16.9, Asme B16.28, Mss Sp 43 |
Stainless Steel Cross Fitting Suppliers in Dubai | SS 304 316 321 347 Corrosion Resistant Cross Fitting
Western Steel Agency is a reputable Stainless Steel Cross Fitting Supplier in Dubai, providing top-notch stainless steel pipe fittings for industrial piping systems. A stainless steel cross fitting is a 4-way pipe fitting that is used to connect and distribute fluid flow in various directions in a pipeline network. These stainless steel fittings are made from high-quality stainless steel grades, offering superior corrosion resistance, durability, and pressure handling. They are very popular in petrochemical plants, water treatment plants, food processing plants, and chemical industries, where it is important to have a reliable distribution of flow. Stainless Steel Cross Fittings come in different sizes and wall thicknesses and are available in different types of connections, depending on the piping needs and operating conditions.
Stainless Steel Cross Fittings are ASTM, ASME, and ANSI Standard Manufactured for high accuracy, leak-free, long-lasting service. These are typically provided via a trusted b2b platform linking contractors, industrial buyers, and engineering companies globally. For directional piping systems, Stainless Steel Elbow Fitting products are also extensively used to make efficient directional changes to the flow without compromising the integrity of the system. Stainless Steel Cross Fittings are widely employed in oil & gas pipelines, chemical processing systems, fire protection networks, hydraulic systems, industrial fluid distribution lines, and applications that require numerous flow connections. They are built to be strong and very resistant to corrosion, suitable for harsh industrial use.
Material & Grades of Stainless Steel Cross Fittings
| Material | Grade / Standard | Specification | Type | Applications |
|---|---|---|---|---|
| Stainless Steel | ASTM A403 WP304 | ASME B16.9 | Buttweld Cross Fitting | General Industrial Piping |
| Stainless Steel | ASTM A403 WP304L | ASME B16.9 | Low Carbon Cross Fitting | Food & Pharmaceutical Industries |
| Stainless Steel | ASTM A403 WP316 | ASME B16.9 | Corrosion Resistant Cross Fitting | Chemical & Marine Applications |
| Stainless Steel | ASTM A403 WP316L | ASME B16.9 | Buttweld Cross Fitting | Oil & Gas Processing |
| Stainless Steel | ASTM A403 WP321 | ASME B16.9 | High Temperature Cross Fitting | Power Plants & Heat Exchangers |
Key Features & Advantages
- Excellent Corrosion Resistance
- High Pressure Resistance
- Superior Weldability
Chemical Composition
| Element | Percentage (%) |
|---|---|
| Chromium (Cr) | 16.0 – 18.0 |
| Nickel (Ni) | 10.0 – 14.0 |
| Molybdenum (Mo) | 2.0 – 3.0 |
| Manganese (Mn) | ≤2.00 |
| Silicon (Si) | ≤1.00 |
| Carbon (C) | ≤0.08 |
| Iron (Fe) | Balance |
Mechanical Properties
| Property | Value |
|---|---|
| Tensile Strength | 515 MPa (Min) |
| Yield Strength | 205 MPa (Min) |
| Elongation | 35% (Min) |
| Hardness | ≤217 HB |
| Operating Temperature | Up to 870°C |
Type of Sub-products
Frequently Asked Questions
Which standards are available for Stainless Steel Cross Fittings?
Are Stainless Steel Cross Fittings suitable for corrosive environments?
What specifications should I check before buying Stainless Steel Cross Fittings?
Which industries use Stainless Steel Cross Fittings?
How can I select suitable Stainless Steel Cross Fittings?
What dimensions are available for Stainless Steel Cross Fittings?
