High Performance Stainless Steel Wire Mesh Manufacturer & Supplier | Ss 304 & Ss 316 Grade | Metaface India

High Performance Stainless Steel Wire Mesh Manufacturer & Supplier | Ss 304 & Ss 316 Grade | Metaface India
Specification Details
StandardAstm A580, A313, A555, A493 / Asme Sa580, Sa313, Sa555, Sa493, Ams 5514
Length0.125", 72
Diameter10 Microns 1.0 Mm, 0.0004" To 0.040"
TechniqueCold Rolled, Hot Rolled

Stainless steel Wire Mesh Manufacturer in India

Metaface India is a leading Stainless Steel Wire Mesh Manufacturer in India. Stainless steel wire mesh and Expanded Metal Wire Mesh is a high-strength, corrosion-resistant material woven or welded from stainless steel wires. Known for its durability and clean, modern appearance, it is widely used across industrial, commercial, and architectural applications. Available in a variety of weave patterns, such as plain weave, twill weave, and Dutch weave, stainless steel mesh offers precision and consistency in opening size, making it ideal for filtration, sieving, screening, and separation processes.

As the leading Stainless Steel Wire Mesh Supplier in India, we provide a product commonly used for protective fencing, railing infills, ceiling panels, sunshades, and cabinet inserts. Grades such as 304 and 316 stainless steel offer varying levels of corrosion resistance and strength, allowing users to choose the right mesh for both indoor and outdoor use.

Material & Grades Table – Stainless Steel Wire Mesh

MaterialGrade / StandardWire Diameter / Opening (mm)Extra SpecificationWeight (kg/m²)
Stainless SteelSS 304 / ASTM A5800.15 – 5.00 / 0.10 – 50Plain / Twill Weave0.40 – 25.00
Stainless SteelSS 304L / ASTM A5800.15 – 5.00 / 0.10 – 50Low Carbon / Welded0.40 – 25.00
Stainless SteelSS 316 / ASTM A5800.15 – 5.00 / 0.10 – 50Corrosion Resistant0.40 – 25.00
Stainless SteelSS 316L / ASTM A5800.15 – 5.00 / 0.10 – 50Marine / Chemical Service0.40 – 25.00
Stainless SteelSS 321 / ASTM A5800.20 – 4.00 / 0.10 – 40High Temperature Service0.50 – 22.00
Stainless SteelSS 310 / ASTM A5800.20 – 4.00 / 0.10 – 40Heat Resistant0.50 – 22.00
Stainless SteelSS 430 / ASTM A5800.20 – 4.00 / 0.10 – 40Ferritic / General Industrial0.50 – 22.00
Stainless SteelSS 904L / ASTM A5800.20 – 3.00 / 0.10 – 25High Corrosion Resistance0.60 – 18.00

Key Features & Advantages

  • Excellent resistance to corrosion and oxidation
  • High tensile strength and dimensional stability
  • Available in fine, medium, and coarse mesh configurations
  • Excellent cleanability for hygienic applications
  • Suitable for filtration, screening, sieving, and separation
  • Good resistance to heat and demanding industrial environments
  • Available in customized mesh counts, wire diameters, and dimensions

Chemical Composition

Representative Grade: Stainless Steel 316L

ElementPercentage (%)
Chromium (Cr)16.0–18.0
Nickel (Ni)10.0–14.0
Molybdenum (Mo)2.0–3.0
Manganese (Mn)2.00 max.
Carbon (C)0.030 max.
Iron (Fe)Balance

Mechanical Properties

PropertyValue
Tensile Strength485 MPa min.
Yield Strength170 MPa min.
Elongation40% min.
Hardness95 HRB max.

Equivalent Grade

StandardGrade
ASTM316L
UNSS31603
EN1.4404
DINX2CrNiMo17-12-2



Type of Sub-products

Frequently Asked Questions

What are Stainless Steel Wire Mesh used for?

Which material should I choose for Stainless Steel Wire Mesh?

Where is Stainless Steel Wire Mesh commonly used?

Which specifications are available for Stainless Steel Wire Mesh?

How do I choose the right Stainless Steel Wire Mesh?

Does Metaface India provide custom manufacturing?

What is the delivery time for Stainless Steel Wire Mesh?
