Corrosion Resistant Welded Wire Mesh Manufacturer & Supplier | Ss 304 Material | Bhansali Wire Mesh

Corrosion Resistant Welded Wire Mesh Manufacturer & Supplier | Ss 304 Material | Bhansali Wire Mesh
Specification Details
StandardAstm A580, A313, A555, A493 / Asme Sa580, Sa313, Ams 5514, Sa555, Sa493
Length0.125", 72
Diameter10 Microns 1.0 Mm, 0.0004" To 0.040"
TechniqueCold Rolled, Hot Rolled

Welded Wire Mesh Manufacturer in india

Bhansali Wire Mesh is a leading Welded Wire Mesh Manufacturers that offers high-quality mesh products that are characterized by their strength, durability, and flexibility. Welded wire mesh is created through the welding of crossing wires in specific intervals of time to create a tough, homogenous mesh. It finds applications in construction, fencing, concrete reinforcement, industrial partitions, and safety applications because of its ability to offer structural support and security, and it is lightweight and easy to manipulate.


The welded wire mesh has been offered in a range of sizes, wire diameters, and coatings to meet the needs of specific projects. These mesh products are very desirable in a B2B marketplace due to the quality in terms of consistency, easy installation, and long service life. Their high load-bearing and corrosion-resistantproperties make them perfect for use in commercial and industrial works, giving them a sure performance in harsh environments. We supply Stainless Steel Wire Mesh, known for its durability, corrosion resistance, and precise filtration.


Welded Wire Mesh – Standard Weight Chart


Wire Diameter (mm)Mesh Size (mm × mm)Weight per Meter (kg)Total Weight per 30 m Roll (kg)
2.0 mm50 × 501.2537.5
2.5 mm50 × 501.9558.5
3.0 mm75 × 752.1063.0
3.5 mm75 × 752.8585.5
4.0 mm100 × 1003.2096.0
5.0 mm100 × 1005.00150.0

Welded Wire Mesh finds extensive application in the work of construction, reinforcement in the construction of concrete, fencing, industrial enclosures, and infrastructure projects because of its toughness and even distribution of the load. An accurate weight chart assists the engineers and the procurement teams in estimating the material loading, transportation needs, and structural conformity. Proper weight information also contributes to the cost calculation, safety management, and project specification compliance, which results in efficient and valid installation.

Key Features & Advantages

  • Strong welded intersections for structural stability
  • Uniform square or rectangular mesh openings
  • High rigidity and dimensional accuracy
  • Suitable for panels and continuous mesh rolls
  • Available in stainless steel, carbon steel, and galvanized options
  • Good resistance to mechanical loads and impact
  • Customizable wire diameters, openings, dimensions, and finishes

Chemical Composition

Representative Grade: Stainless Steel 304

ElementPercentage (%)
Chromium (Cr)18.0–20.0
Nickel (Ni)8.0–10.5
Manganese (Mn)2.00 max
Carbon (C)0.080 max
Silicon (Si)1.00 max
Iron (Fe)Balance

Mechanical Properties

PropertyValue
Tensile Strength515 MPa min.
Yield Strength205 MPa min.
Elongation40% min.
Hardness92 HRB max.

Equivalent Grade

StandardGrade
ASTM304
UNSS30400
EN1.4301
DINX5CrNi18-10



Type of Sub-products

Frequently Asked Questions

What is Welded Wire Mesh?

Which material should I choose for Welded Wire Mesh?

Where is Welded Wire Mesh commonly used?

Which specifications are available for Welded Wire Mesh?

Does Bhansali Wire Mesh provide custom manufacturing?

Where does Bhansali Wire Mesh deliver Welded Wire Mesh?

How can I get a quotation?
