The portfolio is engineered to support a wide range of industrial needs, and add to that, the portfolio has solutions manufactured of high-grade alloys that are used in harsh environments. Among them, the Duplex Steel Wire Mesh is favored in the kind of application that needs high strength along with the increased corrosion and chemical resistance. This kind of mesh works well in the marine, chemical processing and heavy industrial industries. Its microstructure is balanced, which gives it strength and at the same time structural integrity under load. To have an easy procurement and verified sourcing process, a number of buyers use a trusted B2B Platform to reach out to the trusted manufacturer. This will enhance efficiency in the supply process, introduce standardization and facilitation of timely project implementation.

Material & Grades Table – Welded Wire Mesh

Material	Grade / Standard	Size / Thickness / Diameter	Extra Specification	Weight (kg/m²)
Stainless Steel	SS 304 / ASTM A580	10–100 mm opening, 1.0–5.0 mm wire	General-purpose corrosion-resistant mesh	Approx. 2.0–18.0
Stainless Steel	SS 304L / ASTM A580	10–100 mm opening, 1.0–5.0 mm wire	Low-carbon welded mesh	Approx. 2.0–18.0
Stainless Steel	SS 316 / ASTM A580	10–100 mm opening, 1.0–5.0 mm wire	Chemical and marine applications	Approx. 2.0–18.0
Stainless Steel	SS 316L / ASTM A580	10–100 mm opening, 1.0–5.0 mm wire	Corrosive and hygienic environments	Approx. 2.0–18.0
Carbon Steel	ASTM A1064	25–150 mm opening, 2.0–6.0 mm wire	Construction and reinforcement	Approx. 4.0–25.0
Galvanized Steel	ASTM A641	20–150 mm opening, 1.5–6.0 mm wire	Zinc-coated corrosion protection	Approx. 3.0–25.0
High Carbon Steel	SAE 1060	10–100 mm opening, 2.0–6.0 mm wire	Heavy-duty industrial applications	Approx. 4.0–25.0
Aluminium	5052 / ASTM B211	20–100 mm opening, 1.5–5.0 mm wire	Lightweight applications	Approx. 1.0–10.0

Key Features & Advantages

• Strong welded joints at wire intersections
• Uniform square and rectangular openings
• Excellent dimensional stability and rigidity
• Suitable for fencing, reinforcement, and machine guarding
• Good resistance to vibration and mechanical loads
• Stainless steel and galvanized options provide corrosion resistance
• Available in customized wire diameters, opening sizes, and panel dimensions

Chemical Composition

Representative Grade: Stainless Steel 304

Element	Percentage (%)
Chromium (Cr)	18.0–20.0
Nickel (Ni)	8.0–10.5
Manganese (Mn)	2.00 max.
Carbon (C)	0.080 max.
Silicon (Si)	1.00 max.
Iron (Fe)	Balance

Mechanical Properties

Property	Value
Tensile Strength	515 MPa min.
Yield Strength	205 MPa min.
Elongation	40% min.
Hardness	92 HRB max.

Equivalent Grade

Standard	Grade
ASTM	304
UNS	S30400
EN	1.4301
DIN	X5CrNi18-10
