Blind Bolts Manufacturer & Supplier | Stainless Steel 304 & 316 | Delta Fitt Inc

Name: Blind Bolts Manufacturer & Supplier | Stainless Steel 304 & 316 | Delta Fitt Inc
Brand: Delta Fitt Inc
Availability: InStock
Rating: 5 (16 reviews)

Specification Details
Size	20*20
Type	Bolt, Nut, Screw, Washer, Rivet, Threaded Rod, Studs, Coated, Nails, Custom Fasteners
Standard	Din, Iso, Jis, Gb, Is, Bs, Astm
Length	100mm
Material	Stainless Steel, Monel, Inconel, Incoloy, Hastelloy, Nickel, Silicon Bronze, Phosphor Bronze

Trusted Blind Bolt Manufacturer in India Supplying Carbon Steel, Alloy Steel & Stainless Steel Blind Bolts in Grades 8.8, 10.9, 12.9, SS 304 & SS 316

Delta Fitt Inc is the best Blind Bolts Manufacturer providing fastening solutions for locations where backside access is restricted during fitting. They are designed for single-side entry and ensure great holding power by using an expanding mechanism that fits tight against the structure. They are manufactured for fitting in hollow sections, structural beams, and sealed fittings, making them welding and tap-free from the other side. Blind bolts have the reputation of minimizing installation time with consistent strength in load-bearing applications within infrastructure, equipment, and fabrication systems.

Utilized in high-demand B2B engineering and construction industries, blind bolts provide consistent performance within bridges, modular enclosures, and steel structures. With high vibration and environmental stress resistance, they can be applied in dynamic assemblies. Produced in different lengths, diameters, and finishes, they are compatible with composite, aluminum, and steel structures. Their accurate anchoring system is for secure and durable connections in overhead and tight installations. We supply Anchor Bolts engineered to securely fix structural elements to concrete, ensuring strong and stable foundation connections.

Blind Bolts Weight Chart in Kg, MM, PDF

Size (Dia) \ Grip Range	0–6 mm	6–12 mm	12–18 mm	18–24 mm	24–30 mm	30–36 mm	36–42 mm	42–48 mm	48–54 mm	54–60 mm
M6	0.012	0.013	0.014	0.015	0.016	0.017	0.018	0.019	0.020	0.021
M8	0.020	0.022	0.024	0.026	0.028	0.030	0.032	0.034	0.036	0.038
M10	0.034	0.037	0.040	0.043	0.046	0.049	0.052	0.055	0.058	0.061
M12	0.055	0.060	0.065	0.070	0.075	0.080	0.085	0.090	0.095	0.100
M14	0.078	0.084	0.090	0.096	0.102	0.108	0.114	0.120	0.126	0.132
M16	0.100	0.108	0.116	0.124	0.132	0.140	0.148	0.156	0.164	0.172
M18	0.128	0.137	0.146	0.155	0.164	0.173	0.182	0.191	0.200	0.209
M20	0.160	0.172	0.184	0.196	0.208	0.220	0.232	0.244	0.256	0.268
M22	0.198	0.212	0.226	0.240	0.254	0.268	0.282	0.296	0.310	0.324
M24	0.240	0.257	0.274	0.291	0.308	0.325	0.342	0.359	0.376	0.393

Blind bolts are special mechanical bolts that are used where the only access is on one side of the joint. They find extensive applications in construction, automotive, aerospace and heavy engineering industries where conventional nuts and bolts cannot be fitted at the rear. Blind bolts are used to offer good and secure clenching in hollow sections, tubes, and closed profiles to guarantee high load bearing, vibration-free, and structural stability.

These fasteners come in different materials like stainless steel, carbon steel and alloy steel to accommodate the different environments and load conditions. Blind bolts are easily installed, less labour-intensive and have a uniform performance in comparison to the traditional fastening techniques. They offer a perfect solution to contemporary fabrication, maintenance, and retrofit projects that need reliable single-sided fastening due to their corrosion resistance, ease of use and provision of secure joints.

Key Features & Advantages

Can be installed where access is available from one side

Suitable for enclosed and difficult-to-reach assemblies

Provides secure mechanical fastening and clamping

Available in corrosion-resistant stainless steel grades

High-strength options support demanding applications

Suitable for automotive, construction, machinery, and fabrication

Available in different grip ranges, sizes, grades, and finishes

Chemical Composition

Representative Grade: Stainless Steel 316

Element Percentage (%)
Chromium (Cr) 16.0–18.0
Nickel (Ni) 10.0–14.0
Molybdenum (Mo) 2.0–3.0
Manganese (Mn) 2.00 max.
Carbon (C) 0.080 max.
Iron (Fe) Balance

Element	Percentage (%)
Chromium (Cr)	16.0–18.0
Nickel (Ni)	10.0–14.0
Molybdenum (Mo)	2.0–3.0
Manganese (Mn)	2.00 max.
Carbon (C)	0.080 max.
Iron (Fe)	Balance

Mechanical Properties

Property Value
Tensile Strength 515 MPa min.
Yield Strength 205 MPa min.
Elongation 40% min.
Hardness 95 HRB max.

Property	Value
Tensile Strength	515 MPa min.
Yield Strength	205 MPa min.
Elongation	40% min.
Hardness	95 HRB max.

Equivalent Grade

Standard Grade
ASTM F593 Type 316
UNS S31600
EN 1.4401
DIN X5CrNiMo17-12-2

Standard	Grade
ASTM	F593 Type 316
UNS	S31600
EN	1.4401
DIN	X5CrNiMo17-12-2

Type of Sub-products

Frequently Asked Questions

What are Blind Bolts and where are they used?

What materials are available for Blind Bolts?

What is the difference between Stainless Steel 304 and 316 Blind Bolts?

How do I select the right Blind Bolts for my application?

What sizes and specifications are available for Blind Bolts?

Are customized Stainless Steel Blind Bolts available from Delta Fitt Inc?

How can I request a quotation for Blind Bolts through PipeX.ai?
