Advanced Super Duplex Stainless Steel Wire Mesh Manufacturers , Suppliers & Exporters | Uns S32750 & S32760 Grade | H M B Engineering

Advanced Super Duplex Stainless Steel Wire Mesh Manufacturers , Suppliers & Exporters | Uns S32750 & S32760 Grade | H M B Engineering
Specification Details
StandardAstm A580, A313, A555, A493 / Asme Sa580, Sa313, Sa555, Sa493, Ams 5514
Length0.125", 72
Diameter10 Microns 1.0 Mm, 0.0004" To 0.040"
TechniqueCold Rolled, Hot Rolled

Super Duplex Stainless Steel Wire Mesh

HMB Super Duplex Wire Mesh – Unmatched Strength & Corrosion Resistance HMB Engineering offers Super Duplex Stainless Steel Wire Mesh, engineered for industries where extreme strength, durability, and corrosion resistance are crucial. Manufactured from high-grade Super Duplex alloys (UNS S32750 / S32760), our mesh delivers exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking, even in harsh environments. With a balanced microstructure of austenite and ferrite, Super Duplex Wire Mesh combines the strength of ferritic steel with the toughness of austenitic steel—making it highly reliable for marine, chemical, petrochemical, desalination, and offshore applications. HMB’s precision weaving technology ensures accurate apertures, stable performance, and long service life. Available in plain weave, twill weave, and crimped weave patterns, our Super Duplex Wire Mesh is designed to meet international standards like ASTM A240, ASTM A479, and UNS specifications. Choose HMB Super Duplex Wire Mesh for world-class quality, customized sizing, and proven industrial performance.

Material & Grades Table – Super Duplex Stainless Steel Wire Mesh

MaterialGrade / StandardWire Diameter / Opening (mm)Extra SpecificationWeight (kg/m²)
Super Duplex Stainless SteelUNS S32750 / ASTM A5800.20 – 4.00 / 0.50 – 40Plain / Twill Weave0.70 – 22.00
Super Duplex Stainless SteelUNS S32760 / ASTM A5800.20 – 4.00 / 0.50 – 40High Corrosion Resistance0.70 – 22.00
Super Duplex Stainless SteelUNS S327500.30 – 3.50 / 1 – 30Marine / Offshore Service0.80 – 20.00
Super Duplex Stainless SteelUNS S327600.30 – 3.50 / 1 – 30Chemical Processing0.80 – 20.00
Super Duplex Stainless SteelASTM A240 S327500.50 – 3.00 / 1 – 25Industrial Screening1.00 – 18.00
Super Duplex Stainless SteelASTM A240 S327600.50 – 3.00 / 1 – 25Chloride Resistant1.00 – 18.00
Duplex Stainless SteelUNS S322050.20 – 4.00 / 0.50 – 40Duplex Alternative0.70 – 22.00
Super Duplex Stainless SteelUNS S32750 / S327600.50 – 4.00 / 2 – 40Welded / Heavy Duty Mesh1.50 – 25.00

Key Features & Advantages

  • Excellent resistance to chloride-induced corrosion
  • High resistance to pitting and crevice corrosion
  • High tensile and yield strength
  • Superior resistance to stress corrosion cracking
  • Suitable for marine and offshore environments
  • Excellent durability in chemical processing applications
  • Available in customized mesh counts, wire diameters, and weave patterns

Chemical Composition

Representative Grade: Super Duplex Stainless Steel UNS S32750

ElementPercentage (%)
Chromium (Cr)24.0–26.0
Nickel (Ni)6.0–8.0
Molybdenum (Mo)3.0–5.0
Nitrogen (N)0.24–0.32
Manganese (Mn)1.20 max.
Iron (Fe)Balance

Mechanical Properties

PropertyValue
Tensile Strength795 MPa min.
Yield Strength550 MPa min.
Elongation15% min.
Hardness310 HB max.

Equivalent Grade

StandardGrade
ASTMA580 – UNS S32750
UNSS32750
EN1.4410
DINX2CrNiMoN25-7-4



Type of Sub-products

Frequently Asked Questions

What is Super Duplex Wire Mesh used for?

What grades are available at HMB?

How is it better than regular stainless steel wire mesh?

Can HMB provide customized mesh sizes?

Does HMB mesh comply with international standards?
